GE 193X532ADG01现场控制板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE 193X532ADG01 是 General Electric（通用电气）公司 193X 系列中的一款现场控制板，广泛应用于早期 GE 工业驱动系统中，尤其是在直流和交流驱动装置、过程控制系统中，起到核心的现场信号处理和控制指令执行作用。该板卡通常安装于控制机架或控制柜中，与系统内其他功能模块协同运行。
技术规格与功能特点
控制类型：模拟信号控制为主，辅以部分数字逻辑功能
输入信号：标准工业模拟信号（如 0–10V、4–20mA）、数字触点
输出信号：控制电压/电流、开关信号、逻辑控制信号
工作电压：一般为 ±15V DC（系统供电）
调节功能：板载多圈电位器，用于调节增益、零点、响应等参数
电路组成：采用分立电子元器件（运放、晶体管、电容电阻等）构建稳定控制逻辑
接口形式：插卡式金手指设计，连接到 GE 控制机箱背板
状态指示：部分版本带有状态 LED 灯，用于调试与运行指示
应用范围
GE 早期 Mark 系列驱动控制系统
直流/交流电机调速系统
冶金行业电机控制
电厂励磁控制系统
化工、造纸、能源等连续控制流程中的执行机构控制
安装与使用注意事项
安装前确保系统完全断电，插拔过程避免触电或损伤接口。
使用时注意防静电处理，防止静电放电损伤电路元件。
使用前应仔细核对板卡的接线定义、输入输出信号类型与系统要求是否一致。
建议定期（每 6–12 个月）对控制板进行检查，包括电容老化、焊点虚焊、接触不良等问题。
调试过程中可使用示波器、万用表测量关键点信号波形或电压值，判断电路是否正常。
英文资料：
GE 193X532ADG01 is a field control board in General Electric's 193X series, widely used in early GE industrial drive systems, especially in DC and AC drive devices and process control systems, playing a core role in field signal processing and control instruction execution. This board is usually installed in the control rack or control cabinet and operates in conjunction with other functional modules within the system.
Technical specifications and functional features
Control type: mainly analog signal control, supplemented by some digital logic functions
Input signals: standard industrial analog signals (such as 0-10V, 4-20mA), digital contacts
Output signals: control voltage/current, switch signal, logic control signal
Working voltage: generally ± 15V DC (system power supply)
Adjustment function: onboard multi turn potentiometer, used to adjust parameters such as gain, zero point, response, etc
Circuit composition: Using discrete electronic components (operational amplifiers, transistors, capacitors, resistors, etc.) to construct stable control logic
Interface form: Card type gold finger design, connected to the back panel of GE control chassis
Status indicator: Some versions come with status LED lights for debugging and running instructions
Application scope
GE Early Mark Series Drive Control System
DC/AC motor speed control system
Motor control in metallurgical industry
Power plant excitation control system
Control of actuators in continuous control processes such as chemical, papermaking, and energy industries
Installation and usage precautions
Ensure that the system is completely powered off before installation, and avoid electric shock or damage to the interface during the plugging and unplugging process.
Pay attention to anti-static treatment during use to prevent static discharge from damaging circuit components.
Before use, carefully check whether the wiring definition, input and output signal types of the board are consistent with the system requirements.
It is recommended to regularly (every 6-12 months) inspect the control board, including issues such as capacitor aging, solder joint virtual soldering, and poor contact.
During the debugging process, oscilloscopes and multimeters can be used to measure the waveform or voltage values of key point signals to determine if the circuit is functioning properly.
2.产 品 展 示
