ALCATEL LUCENT SNCSBE0AAA电路板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ALCATEL-LUCENT SNCSBE0AAA 电路板 - 技术解析与应用指南
1. 产品定位与核心功能
SNCSBE0AAA是阿尔卡特-朗讯（现诺基亚）的高密度通信电路板，主要承担以下关键功能：
核心数据处理：执行高速数据包转发和协议转换
系统控制中枢：管理板卡资源和设备运行状态
业务接口扩展：提供多种网络接口的物理连接
2. 硬件架构特性
2.1 处理系统
采用多核网络处理器（如Broadcom DNX系列）
配备高速缓存（通常16-32GB DDR4内存）
集成硬件加速引擎（用于加密/解密等特定运算）
2.2 交换架构
支持400Gbps+的交换容量
采用分布式交换矩阵设计
提供无阻塞的数据交换能力
2.3 接口配置
标准配置包含：
4×100G QSFP28光接口
8×25G SFP28光接口
2×10G Base-T电接口
支持热插拔更换
3. 典型应用场景
3.1 电信核心网络
部署于7750 SR核心路由器
承担PE设备功能（MPLS VPN业务边缘）
实现100G骨干网互联
3.2 数据中心网络
用于7450 ESS业务交换机
构建Spine-Leaf架构中的Spine节点
支持VXLAN等 overlay 网络技术
3.3 5G承载网
在5G核心网UPF设备中应用
处理用户面高速数据转发
支持网络切片隔离
英文资料：
ALCATEL-LUCENT SNCSBE0AAA Circuit Board - Technical Analysis and Application Guide
1. Product positioning and core functions
SNCSBE0AAA is a high-density communication circuit board from Alcatel Lucent (now Nokia), mainly responsible for the following key functions:
Core data processing: Perform high-speed packet forwarding and protocol conversion
System Control Center: Manage board resources and device operating status
Business interface extension: providing physical connections for multiple network interfaces
2. Hardware architecture characteristics
2.1 Processing System
Adopting multi-core network processors (such as Broadcom DNX series)
Equipped with high-speed cache (usually 16-32GB DDR4 memory)
Integrated hardware acceleration engine (for specific operations such as encryption/decryption)
2.2 Exchange Architecture
Supports 400Gbps+switching capacity
Adopting a distributed switching matrix design
Provide non blocking data exchange capability
2.3 Interface Configuration
The standard configuration includes:
4 × 100G QSFP28 optical interface
8 × 25G SFP28 optical interface
2 × 10G Base-T electrical interface
Support hot swappable replacement
3. Typical application scenarios
3.1 Telecommunications Core Network
Deploy on 7750 SR core router
Undertake PE device functionality (MPLS VPN service edge)
Realize 100G backbone network interconnection
3.2 Data Center Network
Used for 7450 ESS business switch
Building Spine Nodes in Spine Leaf Architecture
Support overlay network technologies such as VXLAN
3.3 5G Carrier Network
Application in UPF devices of 5G core network
Handling high-speed data forwarding on the user interface
Support network slicing isolation
2.产 品 展 示
