ALCATEL LUCENT 3HE06336AAAA01接口模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ALCATEL-LUCENT 3HE06336AAAA01 接口模块 - 产品详解与应用分析
1. 产品定位与基本功能
3HE06336AAAA01是阿尔卡特-朗讯（现诺基亚）的高性能接口模块，主要用于：
物理层接口扩展：提供多种速率的光/电接口
协议转换：支持不同网络协议的互操作
信号调理：确保信号传输质量和完整性
2. 典型应用场景
2.1 光传输网络
应用于1830 PSS光传输平台
支持：
DWDM波长转换
OTN（G.709）接口
100G/200G高速传输
2.2 IP/MPLS网络
用于7750 SR路由器
功能：
10G/40G/100G以太网接口
MPLS标签处理
QoS策略执行
2.3 5G承载网
前传（eCPRI）和中传接口
支持：
低时延传输（<100μs）
精确时间同步（1588v2）
3. 技术规格（典型）
| 参数 | 规格 |
|---|---|
| 接口类型 | SFP+/QSFP28/CFP2 |
| 速率 | 1G-400G可配置 |
| 协议支持 | Ethernet, OTN, Fibre Channel |
| 传输距离 | 短距(100m)到长距(80km+) |
| 功耗 | <15W（典型值） |
英文资料：
ALCATEL-LUCENT 3HE06336AAAA01 Interface Module - Product Description and Application Analysis
1. Product positioning and basic functions
3HE06336AAAA01 is a high-performance interface module from Alcatel Lucent (now Nokia), mainly used for:
Physical layer interface extension: providing multiple rates of optical/electrical interfaces
Protocol conversion: supports interoperability of different network protocols
Signal conditioning: ensuring signal transmission quality and integrity
2. Typical application scenarios
2.1 Optical Transmission Network
Applied to 1830 PSS optical transmission platform
support:
DWDM wavelength conversion
OTN (G.709) interface
100G/200G high-speed transmission
2.2 IP/MPLS Network
Used for 7750 SR router
Function:
10G/40G/100G Ethernet interface
MPLS label processing
QoS policy execution
2.3 5G Carrier Network
Front transmission (eCPRI) and intermediate transmission interfaces
support:
Low latency transmission (<100 μ s)
Accurate time synchronization (1588v2)
3. Technical specifications (typical)
Parameter specifications
Interface type SFP+/QSFP28/CFP2
Rate of 1G-400G configurable
The protocol supports Ethernet, OTN, Fibre Channel
Transmission distance from short distance (100m) to long distance (80km+)
Power consumption<15W (typical value)
2.产 品 展 示
