ALCATEL LUCENT 3DH03164AB发射器模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ALCATEL-LUCENT 3DH03164AB 发射器模块是专为移动通信基站设计的射频发射组件，主要应用于GSM网络基础设施。该模块采用高效功放设计，工作频段为900MHz，输出功率可达60W，具有优异的线性度和稳定性。
在实际应用中，该模块通常部署在以下场景：
室外宏基站：作为BTS系统的发射单元，为广域覆盖提供射频信号
室内分布系统：用作信号源，通过分布式天线系统实现楼宇内部覆盖
农村网络：解决偏远地区的移动通信覆盖需求
特殊场景：包括隧道、地铁等封闭空间的信号覆盖方案
该模块的主要特点包括：
高效率功放设计，降低能耗
紧凑型结构，便于安装维护
支持远程监控和管理
符合行业标准的接口设计
注意事项：
需由专业技术人员安装调试
确保良好的散热条件
定期进行性能检测和维护
注意防尘防潮保护
英文资料：
The ALCATEL-LUCENT 3DH03164AB transmitter module is a radio frequency transmission component designed specifically for mobile communication base stations, mainly used in GSM network infrastructure. This module adopts an efficient power amplifier design, with a working frequency band of 900MHz and an output power of up to 60W. It has excellent linearity and stability.
In practical applications, this module is usually deployed in the following scenarios:
Outdoor macro base station: As the transmitting unit of the BTS system, it provides RF signals for wide area coverage
Indoor distribution system: used as a signal source to achieve internal coverage of buildings through a distributed antenna system
Rural Network: Addressing the Mobile Communication Coverage Needs in Remote Areas
Special scenarios: signal coverage schemes for enclosed spaces such as tunnels and subways
The main features of this module include:
High efficiency amplifier design, reducing energy consumption
Compact structure, easy to install and maintain
Support remote monitoring and management
Interface design that meets industry standards
matters needing attention:
Installation and debugging by professional technicians are required
Ensure good heat dissipation conditions
Regularly conduct performance testing and maintenance
Pay attention to dust and moisture protection
2.产 品 展 示
