HORNER ELECTRIC  HE693THM884J逻辑控制器 PDF资料

1.产 品 资 料 介 绍：

中文资料：

HORNER ELECTRIC HE693THM884J 是一款 热电偶输入模块，设计用于 GE Fanuc 90-30 PLC 系列。它专门用于接收来自热电偶传感器的温度信号，并将其转换为数字信号供 PLC 进行处理。该模块广泛应用于温度监测和过程控制系统，特别适用于需要高精度温度测量的工业自动化应用。

主要特点：

1. 兼容性

• 该模块专为 GE Fanuc 90-30 PLC 系列设计，并且能与其他 Horner Electric 系列设备兼容。

• 支持 Proficy Machine Edition 或 Logicmaster 90 软件进行配置和编程，确保与现有 PLC 系统无缝集成。

2. 输入通道

• 提供 8 个独立的热电偶输入通道，能够同时接收多个热电偶传感器的信号。

• 每个输入通道都支持 热电偶的多种类型，包括 K型、J型、T型、E型、R型、S型、B型和 N型等。

3. 广泛的热电偶类型支持

• 支持 K型、J型、T型、E型、R型、S型、B型、N型 等多种热电偶类型。

• 允许用户选择适合自己应用的热电偶类型，灵活应用于不同的温度范围和精度要求。

4. 温度测量范围

• K型：-270°C 至 +1372°C

• J型：-210°C 至 +1200°C

• T型：-200°C 至 +400°C

• E型：-200°C 至 +900°C

• R/S型：0°C 至 +1768°C

• B型：+400°C 至 +1820°C

• N型：-200°C 至 +1300°C

• 支持各类热电偶的温度测量范围：

• 各种热电偶的测量范围根据不同的型号有所不同，适应多种工业环境。

5. 冷端补偿功能

• 配备 自动冷端补偿功能，确保测量过程中冷端温度变化不会影响热电偶的信号精度，从而保证温度数据的准确性和可靠性。

6. 高精度与分辨率

• 精度：±0.25%

• 分辨率：根据热电偶类型，分辨率可达到 0.1°C 或更高。

7. 实时数据采集与处理

• 支持 数字化输出，将温度数据实时传输至PLC系统，供控制系统进一步处理和决策。

• 可通过 PLC 程序读取和使用温度数据进行控制。

8. 状态指示与报警功能

• 配备 LED 指示灯，显示模块状态、输入信号及故障警告，便于操作员实时监控设备运行状态。

• 提供 报警功能，用于提示设备故障或温度异常。

英文资料：

HORNER ELECTRIC HE693THM884J is a thermocouple input module designed for the GE Fanuc 90-30 PLC series. It is specifically designed to receive temperature signals from thermocouple sensors and convert them into digital signals for PLC processing. This module is widely used in temperature monitoring and process control systems, especially for industrial automation applications that require high-precision temperature measurement.

Main features:

compatibility

This module is designed specifically for the GE Fanuc 90-30 PLC series and is compatible with other Horner Electric series devices.

Support configuration and programming with Proficy Machine Edition or Logicmaster 90 software to ensure seamless integration with existing PLC systems.

Channel

Provide 8 independent thermocouple input channels that can simultaneously receive signals from multiple thermocouple sensors.

Each input channel supports multiple types of thermocouples, including K-type, J-type, T-type, E-type, R-type, S-type, B-type, and N-type.

Wide range of thermocouple types supported

Supports multiple thermocouple types such as K, J, T, E, R, S, B, N, etc.

Allow users to choose the appropriate thermocouple type for their application, flexibly applying it to different temperature ranges and accuracy requirements.

Temperature measurement range

Support temperature measurement range of various thermocouples:

K-type:- 270 ° C to+1372 ° C

J-type:- 210 ° C to+1200 ° C

T-shaped:- 200 ° C to+400 ° C

Type E:- 200 ° C to+900 ° C

R/S type: 0 ° C to+1768 ° C

Type B:+ 400 ° C to+1820 ° C

N-type:- 200 ° C to+1300 ° C

The measurement range of various thermocouples varies according to different models and is suitable for various industrial environments.

Cold end compensation function

Equipped with automatic cold junction compensation function to ensure that temperature changes at the cold junction during the measurement process do not affect the signal accuracy of the thermocouple, thereby ensuring the accuracy and reliability of temperature data.

High precision and resolution

Accuracy: ± 0.25%

Resolution: Depending on the type of thermocouple, the resolution can reach 0.1 ° C or higher.

Real time data collection and processing

Support digital output, real-time transmission of temperature data to PLC system for further processing and decision-making by the control system.

Temperature data can be read and controlled through PLC programs.

Status indication and alarm function

Equipped with LED indicator lights to display module status, input signals, and fault warnings, facilitating real-time monitoring of equipment operation status by operators.

Provide alarm function to indicate equipment malfunction or abnormal temperature.
