HORNER ELECTRIC HE693RTD601R输入模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
HORNER ELECTRIC HE693RTD601R 是一款 RTD（电阻温度检测）输入模块，用于 GE Fanuc 90-30 PLC 系列，实现多通道高精度温度信号采集和处理。
主要特点：
兼容性
适用于 GE Fanuc 90-30 PLC，作为温度输入模块插入 PLC 机架。
兼容 Horner Electric 自动化系统，提供可靠的温度测量功能。
输入通道
提供 6 个 RTD 传感器输入通道，支持多个 RTD 传感器同时测量。
支持的 RTD 类型
100Ω 铂 RTD（Pt100）
120Ω 镍 RTD（Ni120）
10Ω 铜 RTD（Cu10）
测量范围
Pt100: -200°C ~ 850°C
Ni120: -80°C ~ 260°C
Cu10: -100°C ~ 260°C
分辨率与精度
分辨率：0.1°C
精度：±0.1% 满量程
信号处理与滤波
具有 自动冷端补偿，提高测量精度。
内置 噪声滤波功能，减少工业环境中的电磁干扰。
通信与数据处理
采集的温度数据可以通过 PLC 逻辑程序 直接访问。
支持 模拟量数据转换，用于温度控制和监测应用。
LED 指示灯
具有输入状态和故障指示，便于维护和诊断。
应用领域：
工业自动化（温度监测与控制）
食品加工（温度记录与调节）
HVAC 系统（供暖、通风、空调温度控制）
化工、冶金（过程温度监控）
英文资料：
HORNER ELECTRIC HE693RTD601R is an RTD (Resistance Temperature Detection) input module used in the GE Fanuc 90-30 PLC series to achieve multi-channel high-precision temperature signal acquisition and processing.
Main features:
compatibility
Suitable for GE Fanuc 90-30 PLC, inserted into the PLC rack as a temperature input module.
Compatible with Horner Electric automation system, providing reliable temperature measurement function.
Channel
Provide 6 input channels for RTD sensors, supporting simultaneous measurement by multiple RTD sensors.
Supported RTD types
100 Ω Platinum RTD (Pt100)
120 Ω Nickel RTD (Ni120)
10 Ω Copper RTD (Cu10)
measuring range
Pt100: -200°C ~ 850°C
Ni120: -80°C ~ 260°C
Cu10: -100°C ~ 260°C
Resolution and accuracy
Resolution: 0.1 ° C
Accuracy: ± 0.1% of full scale
Signal Processing and Filtering
Equipped with automatic cold end compensation to improve measurement accuracy.
Built in noise filtering function to reduce electromagnetic interference in industrial environments.
Communication and Data Processing
The collected temperature data can be directly accessed through the PLC logic program.
Support analog data conversion for temperature control and monitoring applications.
LED indicator light
It has input status and fault indication for easy maintenance and diagnosis.
Application areas:
Industrial Automation (Temperature Monitoring and Control)
Food processing (temperature recording and regulation)
HVAC system (heating, ventilation, air conditioning temperature control)
Chemical and metallurgical (process temperature monitoring)
