GE IC3600AOAH1放大器卡 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE IC3600AOAH1 是一款放大器卡（Amplifier Card），隶属于 GE 的 Speedtronic 系列，主要用于信号处理和放大。该模块被广泛应用于涡轮机控制系统中，以增强和稳定从传感器或其他设备接收到的输入信号，从而确保系统运行的准确性和可靠性。
产品特点
信号放大：
- 提供高增益放大功能，用于提升弱信号的强度，使其适合后续的处理和控制。
多通道设计：
- 支持多路信号的并行处理，适合复杂系统的多点监测需求。
信号滤波：
- 集成滤波电路，减少噪声和干扰，确保输出信号的稳定性。
模块化设计：
- 标准化插卡结构，可直接安装到 Speedtronic 系统的背板中，便于维护和替换。
技术规格
输入电压：
- 支持标准低电平信号输入（通常在毫伏或伏特范围内）。
输出电压：
- 放大后的信号输出，范围通常为 0-10V 或 4-20mA（具体根据系统要求）。
增益范围：
- 可调节增益，通常范围为 1x 到 100x。
信号带宽：
- 支持高达 20kHz 的信号放大。
工作环境：
- 温度范围：-20°C 至 +70°C。
- 湿度范围：0%-95%（无冷凝）。
尺寸与接口：
- 标准化尺寸，与 GE Speedtronic 系统兼容。
- 提供多针连接器，确保稳定的电气接触。
英文资料：
GE IC3600AOAH1 is an amplifier card belonging to GE's Speedtronic series, mainly used for signal processing and amplification. This module is widely used in turbine control systems to enhance and stabilize input signals received from sensors or other devices, ensuring the accuracy and reliability of system operation.
Product Features
Signal amplification:
Provide high gain amplification function to enhance the strength of weak signals, making them suitable for subsequent processing and control.
Multi channel design:
Supports parallel processing of multiple signals, suitable for multi-point monitoring requirements of complex systems.
Signal filtering:
Integrated filtering circuit reduces noise and interference, ensuring the stability of the output signal.
Modular design:
Standardized card insertion structure, which can be directly installed into the backplane of the Speedtronic system for easy maintenance and replacement.
technical specifications
Input voltage:
Supports standard low-level signal input (usually in the millivolt or volt range).
Output voltage:
The amplified signal output typically ranges from 0-10V or 4-20mA (depending on system requirements).
Gain range:
Adjustable gain, typically ranging from 1x to 100x.
Signal bandwidth:
Supports signal amplification up to 20kHz.
Work environment:
Temperature range:- 20 ° C to+70 ° C.
Humidity range: 0% -95% (without condensation).
Size and interface:
Standardized dimensions, compatible with GE Speedtronic system.
Provide multi pin connectors to ensure stable electrical contact.
2.产 品 展 示
