GE IC3600SOSF燃气轮机控制模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE IC3600SOSF 是一款燃气轮机控制模块，属于 GE 的 Speedtronic 系列产品，专为燃气轮机系统设计，执行关键的监测和控制任务。以下是该模块的详细信息：
产品概述
GE IC3600SOSF 燃气轮机控制模块通过接收传感器输入信号并输出控制命令，确保燃气轮机的高效、安全和可靠运行。其功能涵盖燃料管理、温度控制和转速调节等关键控制领域。
核心功能
燃气流量控制：
- 管理燃气输入，确保燃料供给与负载需求匹配。
温度监测与保护：
- 通过实时监测燃气轮机温度，提供过热保护功能，避免设备损坏。
转速调节：
- 调节燃气轮机的转速，以适应不同的运行条件和功率需求。
信号处理：
- 接收并处理来自温度传感器、压力传感器和速度传感器的信号，将其转换为控制系统所需的标准信号。
逻辑控制：
- 执行复杂的逻辑算法，确保燃气轮机的稳定运行。
技术规格
输入信号：
- 支持模拟信号输入，例如温度、压力和转速信号。
- 数字信号输入，用于状态监测和安全保护。
输出信号：
- 提供模拟或数字控制信号，用于燃气阀门、点火装置或其他执行机构。
电源要求：
- 工作电压：24V DC 或 48V DC（根据系统配置）。
环境条件：
- 工作温度：-20°C 至 +70°C。
- 湿度范围：0%-95%（无冷凝）。
接口与连接：
- 标准化的多针接口，适用于 GE Speedtronic 系统的模块化安装。
英文资料：
GE IC3600EPSA1A is a frequency converter module belonging to GE's Speedtronic control system series, designed for turbine control and other industrial automation applications. The following is detailed information about the IC3600EPSA1A inverter board:
Product Features
Core functions:
Realize voltage or frequency regulation for controlling motor speed and output power.
Supports variable frequency drive for AC motors, suitable for various industrial applications.
Design features:
Modular design, compatible with the standard framework of GE Speedtronic system.
Onboard various electronic components, including power transistors, capacitors, resistors, and transformers, to achieve efficient frequency conversion.
Integrated control circuit ensures the stability and accuracy of frequency regulation.
Interface and Connection:
Standardized multi pin pin design for quick installation and replacement.
Provide input ports to receive control signals, and output ports to drive loads.
Reliability:
Industrial grade design, suitable for harsh environments such as high temperature, high humidity, and vibration.
Equipped with overload protection and short circuit protection functions to enhance system safety.
technical specifications
Input voltage: typically 24V or 48V DC (matching system configuration).
Output characteristics:
Adjustable output frequency range: 0 Hz to 400 Hz.
Maximum output current: customized according to specific applications and system requirements.
Control type:
Support PWM (Pulse Width Modulation) technology to achieve efficient frequency control.
Work environment:
Temperature range:- 20 ° C to+70 ° C.
Humidity range: 0% -95% (without condensation).
Size and weight:
Compliant with the standard modular dimensions of the Speedtronic system.
Lightweight and easy to install and maintain.
2.产 品 展 示
3.其他产品
4.其他英文产品
