WATLOW CLS204温度控制器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
WATLOW CLS204 温度控制器简介
1. 概述 WATLOW CLS204 是一款高性能温度控制器，设计用于精确控制工业和实验室应用中的温度。它适用于各种加热、冷却和热处理工艺，具备快速响应、易于操作的特点。CLS204 提供多种控制选项和接口，能够满足复杂温控需求。
2. 主要功能
PID 温度控制：支持比例 (P)、积分 (I)、微分 (D) 控制算法，提供精确的温度控制，减少温度波动。
多种输入类型：兼容多种传感器类型，包括热电偶、热电阻 (RTD) 和线性电压/电流输入。
双显示屏：带有双行显示，实时显示过程温度和设定温度，方便操作人员监控和调节。
报警功能：内置多种报警模式，当温度超出设定范围时，能够快速发出报警，确保设备和工艺的安全性。
3. 技术特点
多路输入/输出：支持多个输入/输出通道，允许同时监控和控制多个加热或冷却系统。
自整定功能：控制器具备自整定功能，能够自动调整 PID 参数，优化控制精度和响应速度。
编程灵活：支持用户自定义的温度控制曲线和时间程序，适应各种复杂的温控需求。
多种通讯接口：支持串行通讯（如 Modbus RTU），便于与 PLC、DCS 或其他工业自动化系统集成。
4. 技术规格
型号：CLS204
输入类型：支持热电偶 (J, K, T, E, N, etc.)、RTD、线性电压 (0-10V) 或电流 (4-20mA)
控制输出：继电器、固态继电器 (SSR) 输出或模拟输出
电源要求：通常为 90-240V AC 或 24V DC，具体根据型号而定
显示屏：LED 显示，双行温度显示
报警输出：内置可编程报警，支持多种报警模式（如高/低限报警）
通讯协议：Modbus RTU、RS-485（可选）
尺寸：标准DIN尺寸，易于面板安装
英文资料：
Introduction to WATLOW CLS204 Temperature Controller
1. Overview WATLOW CLS204 is a high-performance temperature controller designed for precise temperature control in industrial and laboratory applications. It is suitable for various heating, cooling, and heat treatment processes, and has the characteristics of fast response and easy operation. CLS204 provides multiple control options and interfaces to meet complex temperature control requirements.
2. Main functions
PID temperature control: supports proportional (P), integral (I), and derivative (D) control algorithms, providing precise temperature control and reducing temperature fluctuations.
Multiple input types: compatible with multiple sensor types, including thermocouples, thermistors (RTDs), and linear voltage/current inputs.
Dual display screen: equipped with dual row display, real-time display of process temperature and set temperature, convenient for operators to monitor and adjust.
Alarm function: Equipped with multiple alarm modes, it can quickly issue an alarm when the temperature exceeds the set range, ensuring the safety of equipment and processes.
3. Technical features
Multi input/output: Supports multiple input/output channels, allowing for simultaneous monitoring and control of multiple heating or cooling systems.
Self tuning function: The controller has self-tuning function, which can automatically adjust PID parameters, optimize control accuracy and response speed.
Flexible programming: supports user-defined temperature control curves and time programs, adapting to various complex temperature control requirements.
Multiple communication interfaces: Supports serial communication (such as Modbus RTU), making it easy to integrate with PLCs, DCS, or other industrial automation systems.
4. Technical specifications
Model: CLS204
Input type: Supports thermocouples (J, K, T, E, N, etc.)、RTD、 Linear voltage (0-10V) or current (4-20mA)
Control output: relay, solid-state relay (SSR) output or analog output
Power requirements: typically 90-240V AC or 24V DC, depending on the model
Display screen: LED display, dual row temperature display
Alarm output: Built in programmable alarm, supporting multiple alarm modes (such as high/low limit alarm)
Communication protocol: Modbus RTU, RS-485 (optional)
Size: Standard DIN size, easy to install on the panel
2.产 品 展 示
