BENTLY 9200-06-02-10-00监测器,9200-06-02-10-00参数说明
第二个引用地址字段包含%I数据的引用地址。这个地址指向%I内存中的位置，其中包含来自模块的状态信息开始。您可以通过编辑来选择报告给PLC的%I状态位置的数量%I大小字段中的值。输入报告给PLC的%I个位置的数量。选项有8、16、24、32或40。数据以以下格式返回：
前八个%I位置：（适用于%I大小值8、16、24、32和40Range选择输入范围的类型和范围。选择为4-20mA、*0-20mA或4-20mA+。
BENTLY 9200-06-02-10-00监测器在4到20mA的默认范围内，从4到20mA的输入电流值报告0到32000个整数CPU的值。在0至20mA范围内，输入电流值范围为0至20mA在0到20mA的输入电流范围内向CPU报告0到32000个整数值。增强的4至20mA范围与默认的4至20mA范围类似，但负值为当输入电流降至4mA以下时报告。在此模式下，如果输入0mA，报告给PLC的值为–8000。低报警输入一个值，使低报警指示传递给PLC。每个通道都有下限报警值（报警下限），导致设置%I点。输入的值假设无符号为正。应进行值检查以确定是否在适当范围内允许报警低值。允许的值为： 4至20mA范围=0至32759 0至20mA范围=0至32759 4至20mA+范围=–8000至+32759报警高输入一个值，使报警高指示传递给PLC。每个通道都有一个上限报警值（报警高），导致设置%I点。不带符号输入的值假设为要积极。应进行值检查，以确定适当范围内允许报警高值。允许的值为： 4至20mA范围=1至32760 0至20mA范围=1至32760 4至20mA+范围=–7999至32760
Address
The second Reference Address field contains the reference address for %I data. The
address points to the location in %I memory where status information from the module
begins. You can select the number of %I status locations reported to the PLC by editing
the value in the %I Size field.
Enter the number of %I locations reported to the PLC. Choices are 8, 16, 24, 32, or 40.
The data is brought back in the following format:
First eight %I locations: (available for %I SIZE values 8, 16, 24, 32, and 40Range Select the type of input range and the ranges. Choices are 4 -20mA,* 0-20mA, or 4-20mA+.
In the 4 to 20mA default range, input current values ranging from 4 to 20mA report 0 to 32,000 integer
values to the CPU. In the 0 to 20mA range, input current values ranging from 0 to
20mA report 0 to 32,000 integer values to the CPU over an input current range of 0 to 20mA.
The enhanced 4 to 20mA range operates like the default 4 to 20mA range, except that negative values are
reported when the input current drops below 4mA. In this mode, if 0mA is input,
the value reported to the PLC is –8,000.
Alarm Low Enter a value that causes an alarm low indication to be passed to the PLC. Each channel has
a low limit alarm value (ALARM LO), which causes %I points to be set. Values entered
without a sign are assumed to be positive. Value checking should be done to determine if
the alarm low values are allowed for the appropriate range. The values allowed are:
4 to 20mA Range = 0 to 32759
0 to 20mA Range = 0 to 32759
4 to 20mA+ Range = –8,000 to +32759
Alarm High Enter a value that causes an alarm high indication to be passed to the PLC. Each channel has a high limit
alarm value (ALARM HI), which causes %I points to be set. Values entered without a sign are assumed to
be positive. Value checking should be done to determine if the
alarm high values are allowed for the appropriate range. The values allowed are:
4 to 20mA Range = 1 to 32760
0 to 20mA Range = 1 to 32760
4 to 20mA+ Range = –7999 to 32760
