Contec SMC-4P(PCI)电机控制板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Contec SMC-4P(PCI) 是一款专为精确控制多轴电机设计的运动控制板，采用 PCI 总线接口，广泛应用于自动化控制和工业设备领域。以下是该电机控制板的详细信息：
主要特点
- 产品型号: SMC-4P(PCI)
- 制造商: Contec
- 类型: 电机控制板（多轴运动控制）
- 接口: PCI 总线
- 轴数: 支持 4 轴电机控制
主要功能
- 多轴电机控制: 该控制板支持同步控制多达 4 个电机，适合应用于复杂的运动控制场景，如 CNC 机床、自动化装配线等。
- 脉冲输出: 支持高达数百 KHz 的脉冲输出频率，用于控制步进电机或伺服电机的精确运动。
- 直线和圆弧插补: 支持多轴之间的直线和圆弧插补运动，使复杂路径的运动控制更加简单高效。
- 位置控制: 提供位置、速度和加速度的闭环控制功能，确保电机运动的精度和响应速度。
- 限位和急停功能: 集成硬件限位、急停输入，确保设备安全运行。
技术参数
- 电机类型: 支持步进电机和伺服电机的脉冲控制。
- 输入/输出: 提供多路数字输入和输出接口，支持限位开关、急停按钮等外部设备的连接。
- 脉冲频率: 最大脉冲频率支持数百 KHz，适合高精度、高速运动控制需求。
- 驱动方式: 支持脉冲 + 方向的控制方式。
软件支持
- 开发环境: 支持 Windows 操作系统下的应用开发，提供标准的 API 接口和开发库，支持 C/C++、C#、VB 等常用编程语言。
- 控制软件: 可搭配 Contec 的运动控制软件，进行图形化的参数设置和实时监控。
英文资料：
Contec SMC-4P (PCI) is a motion control board designed specifically for precise control of multi axis motors. It uses a PCI bus interface and is widely used in the fields of automation control and industrial equipment. The following is the detailed information of the motor control board:
main features
Product model: SMC-4P (PCI)
Manufacturer: Contec
Type: Motor Control Board (Multi axis Motion Control)
Interface: PCI bus
Axis number: Supports 4-axis motor control
major function
Multi axis motor control: This control board supports synchronous control of up to 4 motors, making it suitable for complex motion control scenarios such as CNC machine tools, automated assembly lines, etc.
Pulse output: Supports pulse output frequencies up to several hundred KHz, used to control the precise motion of stepper motors or servo motors.
Linear and Arc Interpolation: Supports linear and arc interpolation motion between multiple axes, making motion control of complex paths simpler and more efficient.
Position control: Provides closed-loop control of position, velocity, and acceleration to ensure the accuracy and response speed of motor motion.
Limit and emergency stop function: Integrated hardware limit and emergency stop input to ensure safe operation of the equipment.
technical parameter
Motor type: Supports pulse control for stepper motors and servo motors.
Input/Output: Provides multiple digital input and output interfaces, supporting the connection of external devices such as limit switches and emergency stop buttons.
Pulse frequency: The maximum pulse frequency supports several hundred KHz, suitable for high-precision and high-speed motion control requirements.
Drive mode: Supports pulse+direction control mode.
Software support
Development environment: Supports application development under the Windows operating system, provides standard API interfaces and development libraries, and supports common programming languages such as C/C++, C #, VB, etc.
Control software: Can be paired with Contec's motion control software for graphical parameter settings and real-time monitoring.
