CONTEC PIO-16/16L(LPCI)H数据采集卡 PDF资料
1.产 品 资 料 介 绍：
中文资料：
CONTEC PIO-16/16L(LPCI)H 是一款 低调PCI（LPCI） 总线接口的数字输入/输出采集卡，专为空间有限的工业自动化、测试控制系统和设备控制应用而设计。它提供 16 路数字输入 和 16 路数字输出，适合各种工业应用中的信号采集和设备控制。
主要特点：
16 路数字输入/输出：
- 16 路数字输入：用于采集外部设备的数字信号，支持多种电压输入模式。
- 16 路数字输出：用于控制外部设备，如继电器、指示灯和其他数字设备。
低调PCI（LPCI）设计：
- 紧凑型设计：适用于空间有限的系统，如工业 PC 或嵌入式控制系统，兼容低调PCI插槽。
光电隔离：
- 输入和输出通道均采用 光电隔离 设计，提供电气隔离，防止电气干扰，提升设备和系统的稳定性与安全性。
高速数据传输：
- 具备高效的数据传输能力，适合需要快速响应的应用场景，如实时控制和高速数据采集。
多操作系统支持：
- 提供 Windows 和 Linux 驱动程序，支持多种编程环境和语言（如 C、C++、LabVIEW），方便用户快速集成到不同的应用系统中。
状态指示灯：
- 配备输入输出状态指示灯，帮助用户监控实时状态，便于设备调试和故障排查。
可编程逻辑电平：
- 用户可通过编程灵活配置输入和输出的逻辑电平，以适应不同的应用需求。
应用场景：
工业自动化控制：
- 用于控制生产线设备和自动化系统中的数字信号输入输出，例如电机控制、设备运行状态检测等。
数据采集与监控：
- 在测试和监控系统中采集设备的数字信号，并实时进行监控和分析，适用于质量控制、设备运行监测等。
设备控制与管理：
- 用于控制外部执行机构和设备，例如阀门、继电器等数字设备，确保系统按预期运行。
科研与开发：
- 支持各种实验室和研发环境，用于新系统的开发和现有系统的优化，采集和控制数据进行分析和实验。
总结：
CONTEC PIO-16/16L(LPCI)H 数据采集卡以其紧凑的低调设计、强大的数字输入输出功能、可靠的光电隔离技术和广泛的系统兼容性，适合多种工业自动化、控制和数据采集应用。它在空间有限的环境中提供高效的数据传输和控制功能，是设备控制和工业应用的理想选择。
英文资料：
The CONTEC PIO-16/16L (LPCI) H is a low profile PCI (LPCI) bus interface digital input/output acquisition card designed specifically for industrial automation, testing control systems, and equipment control applications with limited space. It provides 16 digital inputs and 16 digital outputs, suitable for signal acquisition and device control in various industrial applications.
Main features:
16 channels of digital input/output:
16 channel digital input: used to collect digital signals from external devices, supporting multiple voltage input modes.
16 channel digital output: used to control external devices such as relays, indicator lights, and other digital devices.
Low profile PCI (LPCI) design:
Compact design: Suitable for systems with limited space, such as industrial PCs or embedded control systems, compatible with low profile PCI slots.
Optoelectronic isolation:
Both input and output channels are designed with optoelectronic isolation to provide electrical isolation, prevent electrical interference, and enhance the stability and safety of equipment and systems.
High speed data transmission:
Capable of efficient data transmission, suitable for application scenarios that require quick response, such as real-time control and high-speed data collection.
Multi operating system support:
Provide Windows and Linux drivers, supporting multiple programming environments and languages (such as C, C++, LabVIEW), making it easy for users to quickly integrate into different application systems.
Status indicator light:
Equipped with input/output status indicator lights to help users monitor real-time status, facilitating device debugging and troubleshooting.
Programmable logic level:
Users can flexibly configure the logic levels of inputs and outputs through programming to meet different application requirements.
Application scenarios:
Industrial automation control:
Used for controlling the input and output of digital signals in production line equipment and automation systems, such as motor control, equipment operation status detection, etc.
Data collection and monitoring:
Collecting digital signals from devices in testing and monitoring systems, and conducting real-time monitoring and analysis, suitable for quality control, equipment operation monitoring, etc.
Equipment control and management:
Used to control external actuators and equipment, such as valves, relays, and other digital devices, to ensure that the system operates as expected.
Research and Development:
Support various laboratory and R&D environments for the development of new systems and optimization of existing systems, collecting and controlling data for analysis and experimentation.
Summary:
The CONTEC PIO-16/16L (LPCI) H data acquisition card is suitable for various industrial automation, control, and data acquisition applications due to its compact and low profile design, powerful digital input and output functions, reliable optoelectronic isolation technology, and wide system compatibility. It provides efficient data transmission and control functions in environments with limited space, making it an ideal choice for device control and industrial applications.
2.产 品 展 示
