CONTEC PI-64L(PCI)H数字 I/O PDF资料
1.产 品 资 料 介 绍：
中文资料：
CONTEC PI-64L(PCI)H 是一款数字输入/输出 (DIO) PCI卡，用于数据采集和工业自动化应用。它提供了64个数字I/O通道，适用于需要大量数字信号处理的应用场景。以下是该卡的一些关键规格和特点：
主要特点
数字输入/输出通道：
- 通道数：64个数字I/O通道。
- 配置：可以通过软件配置为输入或输出模式。
- 输入/输出电压：支持标准TTL电平（通常为5V）。
接口：
- 接口类型：PCI接口，适用于标准的PCI插槽。
功能和性能：
- 高速操作：提供高速的数据传输，适合实时数据处理。
- 灵活配置：通道可以单独配置为输入或输出，满足不同的应用需求。
- 中断功能：支持中断功能，可以在输入信号变化时触发中断，适用于需要高响应速度的应用。
驱动和软件支持：
- 驱动程序：支持常见的操作系统（如Windows），提供相应的驱动程序。
- 软件支持：通常配备开发工具和API，帮助用户进行应用开发和系统集成。
应用领域：
- 工业自动化：用于监控和控制工业设备，采集和发送数字信号。
- 测试和测量：用于实验室测试和数据采集系统，处理数字输入和输出。
- 过程控制：在过程控制系统中用于数字信号的实时采集和响应。
安装和维护
- 安装：请根据CONTEC提供的用户手册进行正确的PCI卡安装。
- 驱动程序：确保安装了适用于操作系统的驱动程序，以实现卡的正常功能。
- 配置：通过提供的配置工具或API进行数字I/O通道的设置和调试。
- 维护：定期检查卡的连接和功能，以确保其正常运行，并进行必要的维护。
英文资料：
The CONTEC PI-64L (PCI) H is a digital input/output (DIO) PCI card used for data acquisition and industrial automation applications. It provides 64 digital I/O channels, suitable for applications that require a large amount of digital signal processing. Here are some key specifications and features of the card:
main features
Digital input/output channels:
Number of channels: 64 digital I/O channels.
Configuration: It can be configured as an input or output mode through software.
Input/output voltage: Supports standard TTL level (usually 5V).
Interface:
Interface type: PCI interface, suitable for standard PCI slots.
Function and performance:
High speed operation: Provides high-speed data transmission, suitable for real-time data processing.
Flexible configuration: Channels can be individually configured as inputs or outputs to meet different application requirements.
Interrupt function: Supports interrupt function, can trigger interrupt when input signal changes, suitable for applications that require high response speed.
Driver and software support:
Driver: Supports common operating systems (such as Windows) and provides corresponding drivers.
Software support: Typically equipped with development tools and APIs to assist users in application development and system integration.
Application areas:
Industrial automation: used for monitoring and controlling industrial equipment, collecting and sending digital signals.
Testing and Measurement: Used for laboratory testing and data acquisition systems, processing digital inputs and outputs.
Process control: Used for real-time acquisition and response of digital signals in process control systems.
Installation and maintenance
Installation: Please install the PCI card correctly according to the user manual provided by CONTEC.
Driver program: Ensure that the driver program suitable for the operating system is installed to achieve the normal function of the card.
Configuration: Set up and debug digital I/O channels through the provided configuration tools or APIs.
Maintenance: Regularly check the connection and functionality of the card to ensure its proper operation and perform necessary maintenance.
2.产 品 展 示
