CONTEC DA12-4(PCI) 数据卡 PDF资料

1.产 品 资 料 介 绍：

中文资料：

CONTEC DA12-4(PCI) 数据卡是一款高性能的多通道模拟输出卡，主要用于工业自动化、测试与测量领域中的模拟信号控制。该数据卡通过标准的PCI接口连接到计算机，能够输出精确的模拟信号，适合需要模拟控制和数据生成的应用场景，如过程控制、设备驱动和实验室测试。

主要特点：

1. 多通道模拟输出：

• 4个模拟输出通道：该卡提供4个独立的模拟输出通道，能够同时生成多个模拟信号，适用于需要多信号控制的系统。
• 12位分辨率：每个通道的D/A转换器提供12位分辨率，确保高精度的模拟信号输出，适合对精度要求较高的应用场合。
• 可调电压输出范围：支持多种输出电压范围（如0-5V、0-10V、±5V、±10V），用户可以根据需要进行配置，确保与外部设备的兼容性。

2. 高速D/A转换：

• 具备高速D/A转换功能，能够实时输出模拟信号，适用于需要连续信号输出的应用场景。
• 输出信号的转换速度快，适合动态信号控制，如伺服控制、反馈控制和精密实验等。

3. 板载FIFO缓存：

• 内置FIFO缓存，用于临时存储数据，确保在高速数据传输情况下信号不会丢失，从而保证信号输出的稳定性和连续性。
• FIFO缓冲还可以提高系统的响应速度，避免信号延迟问题。

4. 标准PCI接口：

• 使用标准PCI接口，兼容多数工业PC和商用PC平台，便于安装和配置。
• 提供快速数据传输，确保信号输出的实时性。

5. 触发功能和定时控制：

• 支持软件触发和硬件触发，用户可以根据实际应用选择合适的触发模式，灵活应对各种应用需求。
• 提供定时控制功能，能够精确控制信号的输出时间和频率，适合同步采集和实时控制系统。

6. 数字输入输出：

• 除了模拟输出功能，该卡还可能支持一定数量的数字输入/输出端口，用于简单的状态监控和控制任务（具体型号功能以实际为准）。

7. 软件支持：

• 提供全面的软件开发工具包（SDK），支持Windows和Linux等主流操作系统，并兼容C/C++、LabVIEW等开发环境，用户可以轻松集成到现有系统中。
• 提供便捷的API接口，用户可以根据需求进行二次开发，实现自定义功能和复杂控制任务

英文资料：

The CONTEC DA12-4 (PCI) data card is a high-performance multi-channel analog output card primarily used for analog signal control in the fields of industrial automation, testing, and measurement. This data card is connected to a computer through a standard PCI interface and can output accurate analog signals, suitable for application scenarios that require analog control and data generation, such as process control, device drivers, and laboratory testing.

Main features:

Multi channel analog output:

4 Analog Output Channels: This card provides 4 independent analog output channels, capable of generating multiple analog signals simultaneously, suitable for systems that require multi signal control.

12 bit resolution: The D/A converter of each channel provides 12 bit resolution, ensuring high-precision analog signal output, suitable for applications with high precision requirements.

Adjustable voltage output range: Supports multiple output voltage ranges (such as 0-5V, 0-10V, ± 5V, ± 10V), users can configure according to their needs to ensure compatibility with external devices.

High speed D/A conversion:

Equipped with high-speed D/A conversion function, capable of real-time output of analog signals, suitable for application scenarios that require continuous signal output.

The conversion speed of output signals is fast, suitable for dynamic signal control, such as servo control, feedback control, and precision experiments.

Onboard FIFO cache:

Built in FIFO cache is used for temporary storage of data, ensuring that signals are not lost during high-speed data transmission, thereby ensuring the stability and continuity of signal output.

FIFO buffering can also improve the system's response speed and avoid signal delay issues.

Standard PCI interface:

Using standard PCI interface, compatible with most industrial and commercial PC platforms, easy to install and configure.

Provide fast data transmission to ensure real-time signal output.

Trigger function and timing control:

Support software triggering and hardware triggering, users can choose the appropriate triggering mode according to their actual application, and flexibly respond to various application needs.

Provide timing control function, which can accurately control the output time and frequency of signals, suitable for synchronous acquisition and real-time control systems.

Digital Input/Output:

In addition to analog output functionality, the card may also support a certain number of digital input/output ports for simple status monitoring and control tasks (specific model functions are subject to actual requirements).

Software support:

We provide a comprehensive software development kit (SDK) that supports mainstream operating systems such as Windows and Linux, and is compatible with development environments such as C/C++and LabVIEW. Users can easily integrate it into existing systems.

Provide convenient API interfaces, allowing users to conduct secondary development according to their needs, achieve custom functions and complex control tasks.

2.产      品      展      示
