CONTEC AD12-16(PCI)E 数据采集卡 PDF资料
1.产 品 资 料 介 绍：
中文资料：
CONTEC AD12-16(PCI)E 是一款高性能的数据采集卡，设计用于高精度的模拟信号采集和处理。它适合用于工业自动化、数据采集、测试与测量以及科研等应用。以下是有关 CONTEC AD12-16(PCI)E 数据采集卡的详细信息：
主要功能
模拟信号采集
- 高分辨率：AD12-16(PCI)E 提供 12 位分辨率的模拟信号采集能力，能够精确地转换和处理模拟信号。
- 多通道输入：支持多达 16 个模拟输入通道，可以同时采集多个信号源的数据，提高数据采集的效率。
数据转换与处理
- 模拟到数字转换：将模拟信号转换为数字信号，支持高精度的 A/D 转换过程。
- 高速数据处理：支持高速的数据采集和处理，适用于实时数据监控和分析。
PCI接口
- 标准PCI接口：通过标准的 PCI 总线接口与计算机主板连接，确保广泛的兼容性。
- 高带宽数据传输：提供高带宽的数据传输通道，适合需要快速数据交换的应用场景。
工业与测试应用
- 设备监控：用于监控工业设备的模拟信号，支持实时数据采集和监测。
- 过程控制：能够对工业生产过程进行实时控制和调整，提升生产效率。
- 实验与测试：用于实验室的信号采集和数据分析，支持科学实验和设备测试。
主要特点
高分辨率
- 12 位分辨率：提供 12 位分辨率的模拟信号采集，确保数据采集的精确性和细致性。
多通道支持
- 16 通道输入：支持最多 16 个模拟输入通道，可以同时采集多个信号，提高系统的灵活性和效率。
- 通道配置：能够根据应用需求配置和选择不同的输入通道。
高速数据传输
- PCI总线接口：通过 PCI 总线接口实现高速数据传输，支持大数据量的实时处理。
- 高带宽：提供充足的带宽，满足高频率数据采集和处理需求。
兼容性与驱动支持
- 广泛兼容：支持多种计算机系统和操作系统，易于集成到现有系统中。
- 驱动程序：配备适用于不同操作系统的驱动程序，简化安装和使用过程。
电气隔离
- 抗干扰设计：具备电气隔离功能，减少外部干扰，确保信号的稳定性和准确性。
软件支持
- 应用软件：可能提供配套的应用软件，支持数据采集、处理和分析，简化用户操作。
英文资料：
The CONTEC AD12-16 (PCI) E is a high-performance data acquisition card designed for high-precision analog signal acquisition and processing. It is suitable for applications such as industrial automation, data acquisition, testing and measurement, and scientific research. The following is detailed information about the CONTEC AD12-16 (PCI) E data acquisition card:
major function
Analog signal acquisition
High resolution: AD12-16 (PCI) E provides 12 bit resolution analog signal acquisition capability, which can accurately convert and process analog signals.
Multi channel input: Supports up to 16 analog input channels and can simultaneously collect data from multiple signal sources, improving data collection efficiency.
Data Conversion and Processing
Analog to Digital Conversion: Convert analog signals to digital signals, supporting high-precision A/D conversion processes.
High speed data processing: supports high-speed data acquisition and processing, suitable for real-time data monitoring and analysis.
PCI interface
Standard PCI interface: Connected to the computer motherboard through a standard PCI bus interface to ensure wide compatibility.
High bandwidth data transmission: Provides a high bandwidth data transmission channel, suitable for application scenarios that require fast data exchange.
Industrial and Testing Applications
Equipment monitoring: used to monitor analog signals of industrial equipment, supporting real-time data acquisition and monitoring.
Process control: capable of real-time control and adjustment of industrial production processes, improving production efficiency.
Experiment and Testing: Used for signal acquisition and data analysis in the laboratory, supporting scientific experiments and equipment testing.
main features
high resolution
12 bit resolution: Provides analog signal acquisition with 12 bit resolution to ensure the accuracy and meticulousness of data acquisition.
Multi channel support
16 channel input: Supports up to 16 analog input channels, which can simultaneously collect multiple signals, improving the flexibility and efficiency of the system.
Channel configuration: Able to configure and select different input channels according to application requirements.
High speed data transmission
PCI bus interface: high-speed data transmission is achieved through the PCI bus interface, supporting real-time processing of large amounts of data.
High bandwidth: Provide sufficient bandwidth to meet the needs of high-frequency data acquisition and processing.
Compatibility and driver support
Wide compatibility: Supports multiple computer systems and operating systems, easy to integrate into existing systems.
Drivers: Equipped with drivers suitable for different operating systems, simplifying the installation and usage process.
Electrical isolation
Anti interference design: equipped with electrical isolation function, reducing external interference, ensuring signal stability and accuracy.
Software support
Application software: may provide supporting application software that supports data collection, processing, and analysis, simplifying user operations.
2.产 品 展 示
