Contec PIO-96W(98)K控制器模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
CONTEC PIO-96W(98)K 是一款高性能的数字输入/输出控制器模块，设计用于需要大量数字信号通道的工业自动化和数据采集系统。它通过 PCI 总线与计算机系统连接，提供了 96 路数字 I/O 通道，适用于各种工业控制和监控应用。
产品规格：
- 产品型号: PIO-96W(98)K
- 制造商: CONTEC
- 输入/输出通道:
- 96路数字 I/O（包括数字输入和数字输出）
- 接口类型: PCI 总线接口
- 输入信号电压: 支持 12-24V DC（具体电压范围请参见产品手册）
- 输出信号类型: TTL 电平或 24V 电平（取决于具体配置）
- 输出负载电流: 通常最大 700mA/通道（具体取决于负载类型）
- 隔离类型: 可能包括光电隔离，以提高系统的电气隔离，减少干扰
- 操作系统支持: 兼容 Windows 和 Linux 操作系统
主要功能：
- 96路数字 I/O: 提供高密度的数字输入和输出通道，满足复杂工业应用的需求。
- 高负载能力: 支持较高的电流和电压负载，适合驱动各种工业设备。
- 光电隔离: 提供电气隔离，减少干扰，提高系统稳定性和可靠性。
产品特点：
- 高通道密度: 96 路 I/O 通道，适合需要大量数字信号的复杂控制系统。
- 即插即用: PCI 总线接口设计，简化了安装和配置过程。
- 工业级设计: 提供强大的抗干扰能力和长期的可靠性，适合工业环境使用。
- 灵活配置: 可配置的 I/O 通道支持多种工业自动化任务。
英文资料：
The CONTEC PIO-96W (98) K is a high-performance digital input/output controller module designed for industrial automation and data acquisition systems that require a large number of digital signal channels. It is connected to computer systems through the PCI bus and provides 96 digital I/O channels, suitable for various industrial control and monitoring applications.
Product specifications:
Product model: PIO-96W (98) K
Manufacturer: CONTEC
Input/output channels:
96 channels of digital I/O (including digital input and digital output)
Interface type: PCI bus interface
Input signal voltage: Supports 12-24V DC (please refer to the product manual for specific voltage range)
Output signal type: TTL level or 24V level (depending on specific configuration)
Output load current: typically up to 700mA/channel (depending on load type)
Isolation type: may include optoelectronic isolation to improve the electrical isolation of the system and reduce interference
Operating system support: compatible with Windows and Linux operating systems
Main functions:
96 channel digital I/O: Provides high-density digital input and output channels to meet the needs of complex industrial applications.
High load capacity: Supports high current and voltage loads, suitable for driving various industrial equipment.
Optoelectronic isolation: provides electrical isolation, reduces interference, and improves system stability and reliability.
Product features:
High channel density: 96 I/O channels, suitable for complex control systems that require a large amount of digital signals.
Plug and play: The PCI bus interface design simplifies the installation and configuration process.
Industrial grade design: Provides strong anti-interference capability and long-term reliability, suitable for use in industrial environments.
Flexible configuration: Configurable I/O channels support multiple industrial automation tasks.
2.产 品 展 示
