CONTEC PIO-32/32T(98)E输入输出模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
CONTEC PIO-32/32T(98)E 是一款输入/输出模块，专为需要同时处理大量数字输入和输出信号的工业应用设计。该模块通过 PCI 总线与计算机系统连接，提供了 32 路数字输入和 32 路数字输出通道，适合于多种工业自动化和数据采集任务。
产品规格：
- 产品型号: PIO-32/32T(98)E
- 制造商: CONTEC
- 输入/输出通道:
- 32路数字输入
- 32路数字输出
- 接口类型: PCI总线接口
- 输入信号电压: 通常支持 12-24V DC（具体电压范围请参见产品手册）
- 输出信号类型: TTL 电平或 24V 电平（取决于配置）
- 输出负载电流: 通常最大 700mA/通道（具体取决于负载类型）
- 隔离类型: 可能包括光电隔离，确保输入和输出通道之间的电气隔离，减少干扰
- 操作系统支持: 兼容 Windows 和 Linux 操作系统
主要功能：
- 32路数字输入: 用于采集来自外部设备的状态信号，实现实时监控和数据采集。
- 32路数字输出: 用于控制各种执行器、继电器等设备，实现自动化控制。
- 光电隔离: 提供电气隔离，减少信号干扰，提高系统稳定性和可靠性。
产品特点：
- 高通道密度: 同时支持 32 路输入和 32 路输出，适合复杂的工业控制应用。
- 即插即用: PCI 总线接口即插即用，简化了安装和配置过程。
- 工业级设计: 具备较强的抗干扰能力和可靠性，适合在严苛的工业环境下使用。
- 高负载能力: 输出通道能够支持较高电流和电压，适合驱动各种工业设备。
英文资料：
The CONTEC PIO-32/32T (98) E is an input/output module designed for industrial applications that require the simultaneous processing of a large number of digital input and output signals. This module is connected to the computer system through the PCI bus, providing 32 digital input and 32 digital output channels, suitable for various industrial automation and data acquisition tasks.
Product specifications:
Product model: PIO-32/32T (98) E
Manufacturer: CONTEC
Input/output channels:
32 channel digital input
32 digital outputs
Interface type: PCI bus interface
Input signal voltage: usually supports 12-24V DC (please refer to the product manual for specific voltage range)
Output signal type: TTL level or 24V level (depending on configuration)
Output load current: typically up to 700mA/channel (depending on load type)
Isolation type: may include optoelectronic isolation, ensuring electrical isolation between input and output channels to reduce interference
Operating system support: compatible with Windows and Linux operating systems
Main functions:
32 channel digital input: used to collect status signals from external devices for real-time monitoring and data acquisition.
32 channel digital output: used to control various actuators, relays, and other equipment to achieve automation control.
Optoelectronic isolation: provides electrical isolation, reduces signal interference, and improves system stability and reliability.
Product features:
High channel density: Supports both 32 inputs and 32 outputs, suitable for complex industrial control applications.
Plug and play: The PCI bus interface is plug and play, simplifying the installation and configuration process.
Industrial grade design: It has strong anti-interference ability and reliability, suitable for use in harsh industrial environments.
High load capacity: The output channel can support high currents and voltages, suitable for driving various industrial equipment.
2.产 品 展 示
