1.产 品 资 料 介 绍：
中文资料：
CONTEC PIO-24/24B(98) 是一款高性能的数字输入/输出接口电路板，专门设计用于工业自动化、数据采集和控制系统中。它通过 PCI 总线与计算机系统连接，提供 24 路数字输入和 24 路数字输出通道，适合用于各种复杂的工业控制任务。
产品规格：
- 产品型号: PIO-24/24B(98)
- 制造商: CONTEC
- 输入/输出通道:
- 24路数字输入
- 24路数字输出
- 接口类型: PCI总线接口
- 输入信号电压: 12-24V DC
- 输出信号类型: TTL 电平或 24V 电平
- 输出负载电流: 最大 700mA/通道
- 隔离类型: 光电隔离，提供输入和输出通道之间的电气隔离
- 操作系统支持: Windows 和 Linux
主要功能：
- 24路数字输入: 允许用户从外部设备（如传感器、开关）采集信号，实现实时监控和反馈。
- 24路数字输出: 可用于控制各种设备，如继电器、执行器等，支持多种自动化任务。
- 光电隔离: 提供输入和输出通道的电气隔离，减少电气噪声干扰，提升系统的稳定性和安全性。
- 高负载能力: 输出通道支持较高电流和电压，能够驱动多种工业设备。
产品特点：
- 高通道密度: 提供 24 路输入和 24 路输出，适合复杂的控制和监控应用。
- 即插即用: 支持 PCI 总线即插即用功能，方便安装和配置，减少系统集成时间。
- 工业级设计: 具备强大的抗干扰能力和可靠性，适应各种工业环境。
- 灵活应用: 支持多种操作系统，适合不同的自动化系统集成需求。
英文资料：
The CONTEC PIO-24/24B (98) is a high-performance digital input/output interface circuit board specifically designed for use in industrial automation, data acquisition, and control systems. It is connected to the computer system through the PCI bus, providing 24 digital input and 24 digital output channels, suitable for various complex industrial control tasks.
Product specifications:
Product model: PIO-24/24B (98)
Manufacturer: CONTEC
Input/output channels:
24 channel digital input
24 digital outputs
Interface type: PCI bus interface
Input signal voltage: 12-24V DC
Output signal type: TTL level or 24V level
Output load current: maximum 700mA/channel
Isolation type: photoelectric isolation, providing electrical isolation between input and output channels
Operating system support: Windows and Linux
Main functions:
24 channel digital input: allows users to collect signals from external devices (such as sensors, switches) for real-time monitoring and feedback.
24 channel digital output: can be used to control various devices such as relays, actuators, etc., supporting multiple automation tasks.
Optoelectronic isolation: provides electrical isolation of input and output channels, reduces electrical noise interference, and enhances system stability and safety.
High load capacity: The output channel supports high currents and voltages, and can drive various industrial equipment.
Product features:
High channel density: Provides 24 inputs and 24 outputs, suitable for complex control and monitoring applications.
Plug and play: Supports PCI bus plug and play functionality, facilitating installation and configuration, and reducing system integration time.
Industrial grade design: With strong anti-interference ability and reliability, it can adapt to various industrial environments.
Flexible application: Supports multiple operating systems, suitable for different automation system integration requirements.
2.产 品 展 示
