CONTEC PI-48(98) 电路板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
CONTEC PI-48(98) 是一款用于工业自动化和控制系统的电路板，主要用于多通道的数字输入/输出（I/O）任务。它适用于需要大量 I/O 通道的应用，能够支持各种外部设备的信号处理。
主要特点：
- 48 路数字 I/O：PI-48(98) 提供 48 路数字输入/输出通道，能够处理多个设备的信号输入和输出，非常适合复杂的自动化控制系统。
- ISA 总线接口：该电路板通过标准的 ISA 总线接口与计算机系统连接，适合旧式工业计算机系统，特别是需要与传统控制系统兼容的场合。
- 灵活的 I/O 配置：每个通道可以独立配置为输入或输出，支持多种配置需求。例如，可以配置为输入以读取传感器信号，或配置为输出以控制执行器。
- 电气隔离：提供 I/O 通道的电气隔离功能，防止外部设备的电气干扰影响系统运行，确保数据传输的稳定性和系统的可靠性。
- 高抗干扰能力：设计上注重抗干扰能力，适应工业环境中可能存在的电气噪声和干扰，保证模块在复杂环境下稳定运行。
技术规格：
- I/O 通道数量：48 路数字输入/输出通道，可以灵活配置为输入或输出模式。
- 总线接口：采用 ISA 总线接口，适合传统工业计算机系统。
- 输入/输出信号类型：能够处理数字开关信号、按钮状态、传感器数据等。
- 电气隔离：具备电气隔离功能，防止外部电气干扰。
- 工作环境：设计用于工业环境，具有较高的抗干扰能力。
应用场景：
- 工业自动化：在自动化生产线或工厂控制系统中，PI-48(98) 提供多通道 I/O 支持，用于控制和监测多个设备。
- 数据采集：用于采集外部设备的数据，并将其传输到计算机系统进行分析和处理。
- 设备控制：实现对各种设备的控制，例如启动和停止执行器、读取传感器数据等。
英文资料：
CONTEC PI-48 (98) is a circuit board used in industrial automation and control systems, primarily for multi-channel digital input/output (I/O) tasks. It is suitable for applications that require a large number of I/O channels and can support signal processing for various external devices.
Main features:
48 digital I/O: PI-48 (98) provides 48 digital input/output channels, capable of processing signal inputs and outputs from multiple devices, making it very suitable for complex automation control systems.
ISA bus interface: This circuit board is connected to computer systems through a standard ISA bus interface, making it suitable for old industrial computer systems, especially those that require compatibility with traditional control systems.
Flexible I/O configuration: Each channel can be independently configured as an input or output, supporting multiple configuration requirements. For example, it can be configured as an input to read sensor signals, or as an output to control actuators.
Electrical isolation: Provides electrical isolation function for I/O channels to prevent electrical interference from external devices from affecting system operation, ensuring the stability of data transmission and the reliability of the system.
High anti-interference ability: The design emphasizes anti-interference ability, adapts to electrical noise and interference that may exist in industrial environments, and ensures stable operation of the module in complex environments.
Technical specifications:
Number of I/O channels: 48 digital input/output channels, which can be flexibly configured as input or output modes.
Bus interface: Adopting ISA bus interface, suitable for traditional industrial computer systems.
Input/output signal type: capable of processing digital switch signals, button status, sensor data, etc.
Electrical isolation: It has electrical isolation function to prevent external electrical interference.
Work environment: Designed for industrial environments with high anti-interference ability.
Application scenarios:
Industrial Automation: In automated production lines or factory control systems, PI-48 (98) provides multi-channel I/O support for controlling and monitoring multiple devices.
Data collection: used to collect data from external devices and transmit it to a computer system for analysis and processing.
Device control: Implement control over various devices, such as starting and stopping actuators, reading sensor data, etc.
