3BSE017235R1控制面板,PXAH401使用参数
这些块与早期版本向后兼容，并且可用于更换。可以使用任何手持式监视器（IC66*HHM500或HHM501）用这些积木。然而，手持式监视器模型IC66*HHM501需要更改波特率配置，或配置冗余功能。注意，较旧的HHM模型IC66*HHM501版本3.5可能会错误显示消息正常运行期间的接线错误。将HHM升级为更高版本更正了此问题。
3BSE017235R1控制面板对于IC697系列PLC，CPU和编程软件必须版本2.0或更高版本。总线控制器必须为IC697BEM731C或更晚。对于IC600系列PLC，CPU必须为rev。105或更高版本。对于IC600系列“Plus”PLC版本。需要110或更高版本。这个编程软件必须是rel。4.02或更高版本。对于IC550系列PLC，CPU必须为rev。3.0或更高版本。这个编程软件必须是rel。2.01或更高版本。电流回路首选电流源模拟块应用。请提供以下信息：
115VAC/125VDC电流源模拟4输入/2输出块（IC66*BBA104）
24/48 VDC电流源模拟4输入/2输出块（IC66*BBA024）
115VAC/125VDC电流源模拟输出块（IC66*BBA105）
115VAC/125VDC电流源模拟输入块（IC66*BBA106）
24/48 VDC电流源模拟块输入块（IC66*BBA026）本数据表总结了有关块安装的信息，配置和诊断。您的主要参考应该是离散和模拟块用户手册。它包括块安装的详细说明和配置。有关系统和通信的更多信息，包括总线规格，请参阅输入/输出系统和通信手册。安装说明
These blocks are backward-compatible with earlier versions, and
may be used to replace them.
Any Hand-held Monitor (IC66*HHM500 or HHM501) can be used
with these blocks. However, Hand-held Monitor model
IC66*HHM501 is required to change baud rate configuration, or to
configure redundancy features. Note that older HHM model
IC66*HHM501 version 3.5 may incorrectly display the message
WIRING ERROR during normal operation. Upgrading the HHM to a
later version corrects this problem.
For an IC697 series PLC, the CPU and programming software must
be version 2.0 or later. The bus controller must be IC697BEM731C
or later.
For an IC600 series PLC, the CPU must be rev. 105 or later. For an
IC600 series “Plus” PLC rev. 110 or later is required. The
programming software must be rel. 4.02 or later.
For an IC550 series PLC, the CPU must be rev. 3.0 or later. The
programming software must be rel. 2.01 or later.
Current-source analog blocks are preferred for current-loop
applications. Please request information about:
115VAC/125VDC Current-source Analog 4 Input/2 Output Block
(IC66*BBA104)
24/48 VDC Current-source Analog 4 Input/2 Output Block (IC66*BBA024)
115VAC/125VDC Current-source Analog Output Block (IC66*BBA105)
115VAC/125VDC Current-source Analog Input Block (IC66*BBA106)
24/48 VDC Current-source Analog Block Input Block (IC66*BBA026)This datasheet summarizes information about block installation,
configuration, and diagnostics.
Your primary reference should be the Discrete and Analog Blocks
User’s Manual. It includes detailed instructions for block installation
and configuration.
For additional information about systems and communications,
including bus specifications, refer to the I/O System and
Communications Manual.
Installation Instructions
