TRACO TIS600-124-SIG导轨电源模块   PDF资料

1.产 品 资 料 介 绍：

中文资料：

TRACO TIS600-124-SIG 是一款工业级导轨电源模块，广泛应用于需要稳定电源供应的各种场景。以下是该电源模块的详细信息及其应用领域：

产品特点：

1. 高效率：高达93%的转换效率，减少能量损失，提升系统整体效率。
2. 宽输入范围：支持85-264V AC和120-370V DC的宽输入电压范围，适应不同的供电环境。
3. 高功率密度：紧凑的设计和高功率密度，适合空间有限的安装环境。
4. 多重保护功能：具备过载、过压、过温和短路保护，确保设备安全。
5. 并联功能：支持多台电源并联使用，以实现冗余和负载分担，提高系统可靠性。
6. 信号接口：配有信号接口，用于监测和控制电源状态。
7. 安装便捷：DIN导轨安装方式，便于快速安装和维护。

技术参数：

• 输入电压范围：85-264V AC / 120-370V DC
• 输出电压：24V DC
• 输出电流：25A
• 输出功率：600W
• 效率：高达93%
• 工作温度范围：-25°C 至 +70°C
• 保护功能：过载保护、过压保护、过温保护、短路保护
• 信号接口：用于电源状态监测和控制
• 尺寸：130 x 125 x 120 mm

典型应用领域：

1. 工业自动化：

• PLC和控制系统：为PLC、DCS等自动化控制系统提供稳定电源，确保系统的可靠运行。
• 传感器和执行器：为各种工业传感器和执行器供电，支持精确控制和监测。

2. 电信设备：

• 基站设备：为基站和通讯塔的设备提供电力，确保通讯网络的稳定性和连续性。
• 网络设备：为路由器、交换机等网络设备供电，保证数据传输的可靠性。

3. 医疗设备：

• 诊断设备：为CT、MRI等医疗诊断设备供电，确保设备的正常运行和数据的准确性。
• 监护设备：为各类监护仪器提供稳定电源，保障病人的持续监测。

4. 电力和能源系统：

• 电力监控系统：为电力监控和管理系统提供电源，确保电网的稳定和安全。
• 可再生能源系统：用于太阳能、风能等系统中的电能转换和管理。

5. 交通运输：

• 铁路系统：为铁路信号和控制系统提供电源，保障交通运输的安全和效率。
• 航空和航海：为飞机和船舶的导航、通讯设备提供电力，确保其正常运行。

6. 测试和测量设备：

• 实验室仪器：为各种实验室测试和测量设备供电，确保实验数据的准确性和可靠性。
• 现场测试设备：为便携式测试设备供电，支持现场故障诊断和数据采集。

英文资料：

TRACO TIS600-124-SIG is an industrial grade rail power module widely used in various scenarios that require stable power supply. The following is the detailed information and application areas of the power module:

Product features:

High efficiency: up to 93% conversion efficiency, reducing energy loss and improving overall system efficiency.

Wide input range: Supports a wide input voltage range of 85-264V AC and 120-370V DC, suitable for different power supply environments.

High power density: Compact design and high power density, suitable for installation environments with limited space.

Multiple protection functions: equipped with overload, overvoltage, over temperature, and short circuit protection to ensure equipment safety.

Parallel function: Supports the parallel use of multiple power sources to achieve redundancy and load sharing, improving system reliability.

Signal interface: equipped with a signal interface for monitoring and controlling power status.

Easy installation: DIN rail installation method, convenient for quick installation and maintenance.

Technical parameters:

Input voltage range: 85-264V AC/120-370V DC

Output voltage: 24V DC

Output current: 25A

Output power: 600W

Efficiency: up to 93%

Working temperature range: -25 ° C to+70 ° C

Protection functions: overload protection, overvoltage protection, over temperature protection, short circuit protection

Signal interface: used for power status monitoring and control

Size: 130 x 125 x 120 mm

Typical application areas:

Industrial automation:

PLC and control system: Provide stable power supply for automation control systems such as PLC and DCS to ensure reliable operation of the system.

Sensors and actuators: powering various industrial sensors and actuators, supporting precise control and monitoring.

Telecommunications equipment:

Base station equipment: provides power to the equipment of the base station and communication tower, ensuring the stability and continuity of the communication network.

Network equipment: Provides power to network devices such as routers and switches to ensure the reliability of data transmission.

Medical equipment:

Diagnostic equipment: supplies power to medical diagnostic equipment such as CT and MRI to ensure the normal operation of the equipment and the accuracy of data.

Monitoring equipment: provides stable power supply for various monitoring instruments to ensure continuous monitoring of patients.

Power and energy systems:

Power monitoring system: provides power supply for power monitoring and management systems, ensuring the stability and safety of the power grid.

Renewable energy system: used for the conversion and management of electrical energy in solar, wind and other systems.

Transportation:

Railway system: provides power for railway signal and control systems, ensuring the safety and efficiency of transportation.

Aviation and navigation: providing power for navigation and communication equipment of aircraft and ships to ensure their normal operation.

Testing and measuring equipment:

Laboratory instruments: supply power to various laboratory testing and measuring equipment to ensure the accuracy and reliability of experimental data.

On site testing equipment: Provides power to portable testing devices, supports on-site fault diagnosis and data collection.

2.产      品      展      示
