TRACO TIS600-124导轨电源 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TRACO TIS600-124 是一款高性能导轨电源，适用于工业和自动化应用。以下是该电源模块的详细信息及其应用领域：
产品特点：
- 高效率：高达93%的效率，确保低能耗和低热量产生，提高系统整体性能。
- 宽输入范围：支持85-264V AC和120-370V DC的宽输入电压范围，适应多种供电环境。
- 高功率密度：紧凑设计，节省空间，适合在受限空间内安装。
- 多重保护功能：具有过载、过压、过温和短路保护功能，保障设备安全。
- 并联功能：支持多台电源并联使用，以实现冗余和负载分担，提高系统可靠性。
- 安装便捷：DIN导轨安装方式，便于快速安装和维护。
技术参数：
- 输入电压范围：85-264V AC / 120-370V DC
- 输出电压：24V DC
- 输出电流：25A
- 输出功率：600W
- 效率：高达93%
- 工作温度范围：-25°C 至 +70°C
- 保护功能：过载保护、过压保护、过温保护、短路保护
- 尺寸：130 x 125 x 120 mm
典型应用领域：
工业自动化：
- PLC和控制系统：为PLC、DCS等自动化控制系统提供稳定电源，确保系统的可靠运行。
- 传感器和执行器：为各种工业传感器和执行器供电，支持精确控制和监测。
电信设备：
- 基站设备：为基站和通讯塔的设备提供电力，确保通讯网络的稳定性和连续性。
- 网络设备：为路由器、交换机等网络设备供电，保证数据传输的可靠性。
医疗设备：
- 诊断设备：为CT、MRI等医疗诊断设备供电，确保设备的正常运行和数据的准确性。
- 监护设备：为各类监护仪器提供稳定电源，保障病人的持续监测。
电力和能源系统：
- 电力监控系统：为电力监控和管理系统提供电源，确保电网的稳定和安全。
- 可再生能源系统：用于太阳能、风能等系统中的电能转换和管理。
交通运输：
- 铁路系统：为铁路信号和控制系统提供电源，保障交通运输的安全和效率。
- 航空和航海：为飞机和船舶的导航、通讯设备提供电力，确保其正常运行。
测试和测量设备：
- 实验室仪器：为各种实验室测试和测量设备供电，确保实验数据的准确性和可靠性。
- 现场测试设备：为便携式测试设备供电，支持现场故障诊断和数据采集。
英文资料：
TRACO TIS600-124 is a high-performance rail power supply suitable for industrial and automation applications. The following is the detailed information and application areas of the power module:
Product features:
High efficiency: up to 93% efficiency, ensuring low energy consumption and low heat generation, improving overall system performance.
Wide input range: Supports a wide input voltage range of 85-264V AC and 120-370V DC, suitable for various power supply environments.
High power density: Compact design, space saving, suitable for installation in confined spaces.
Multiple protection functions: It has overload, overvoltage, over temperature, and short circuit protection functions to ensure equipment safety.
Parallel function: Supports the parallel use of multiple power sources to achieve redundancy and load sharing, improving system reliability.
Easy installation: DIN rail installation method, convenient for quick installation and maintenance.
Technical parameters:
Input voltage range: 85-264V AC/120-370V DC
Output voltage: 24V DC
Output current: 25A
Output power: 600W
Efficiency: up to 93%
Working temperature range: -25 ° C to+70 ° C
Protection functions: overload protection, overvoltage protection, over temperature protection, short circuit protection
Size: 130 x 125 x 120 mm
Typical application areas:
Industrial automation:
PLC and control system: Provide stable power supply for automation control systems such as PLC and DCS to ensure reliable operation of the system.
Sensors and actuators: powering various industrial sensors and actuators, supporting precise control and monitoring.
Telecommunications equipment:
Base station equipment: provides power to the equipment of the base station and communication tower, ensuring the stability and continuity of the communication network.
Network equipment: Provides power to network devices such as routers and switches to ensure the reliability of data transmission.
Medical equipment:
Diagnostic equipment: supplies power to medical diagnostic equipment such as CT and MRI to ensure the normal operation of the equipment and the accuracy of data.
Monitoring equipment: provides stable power supply for various monitoring instruments to ensure continuous monitoring of patients.
Power and energy systems:
Power monitoring system: provides power supply for power monitoring and management systems, ensuring the stability and safety of the power grid.
Renewable energy system: used for the conversion and management of electrical energy in solar, wind and other systems.
Transportation:
Railway system: provides power for railway signal and control systems, ensuring the safety and efficiency of transportation.
Aviation and navigation: providing power for navigation and communication equipment of aircraft and ships to ensure their normal operation.
Testing and measuring equipment:
Laboratory instruments: supply power to various laboratory testing and measuring equipment to ensure the accuracy and reliability of experimental data.
On site testing equipment: Provides power to portable testing devices, supports on-site fault diagnosis and data collection.
2.产 品 展 示
