功能代码150生成的问题报告为输入/输出错误报告（报告类型12）。功能代码150问题报告生成一种错误类型：错误类型1-无响应/错误类型硬件故障排除通过使用流程图隔离故障，有效地排除硬件故障（见图6-3和6-3）。之后查找故障，请参阅文本或其他参考文件，以了解有关故障和纠正措施的更多信息。请联系制造商以获取控制回路处理硬件故障排除信息。
CI867K01输出逻辑模块第一部分
本节涵盖离线故障。如果故障阻碍校准、调谐或模块启动，请参阅离线故障和故障排除步骤。这个第二部分介绍了操作过程中的故障。如果失败在操作过程中发生，请参阅联机故障和故障排除步骤。注：故障排除涉及与系统的物理接触，包括处理带有静电敏感设备的电路板。
为了避免在故障排除时产生其他问题，请始终工作时使用贝利的现场静态套件（零件号1948385_1）使用模块。该套件用于连接技师和
静电耗散工作面至同一接地点，以防止静电放电对模块造成损坏。
Problem reports generated by function code 150 are I/O error
reports (report type 12). Function code 150 problem reports
generate one error type: Error type 1 - No response/wrong type
(refer to Tables 6-3 and 6-4).
TROUBLESHOOTING HARDWARE FAILURES
Effectively troubleshoot a hardware failure by using the flowcharts to isolate the failure (see Figures 6-3 and 6-3). After
locating the failure, refer to the text or other reference documents for more information about the failure and the corrective action. Contact the manufacturer for control loop processhardware troubleshooting information. The first part of this
section covers off-line failures. If the failure is preventing calibration, tuning or module start-up, refer to OFF-LINE FAILURE and the steps of the troubleshooting procedure. The
second part covers failures during operation. If the failure
occurs during operation, refer to ON-LINE FAILURE and the
steps of the troubleshooting procedure.
NOTE: Troubleshooting involves physical contact with the system,
including the handling of boards with electrostatic sensitive devices.
To avoid creating additional problems while troubleshooting, always
use Bailey’s field static kit (part number 1948385_1) when working
with the modules. The kit is designed to connect a technician and
the static dissipative work surface to the same ground point to prevent damage to the modules by electrostatic discharge.
