MULTILIN MIFPI11E100H00数字馈电继电器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
MULTILIN MIFPI11E100H00数字馈电继电器是一种用于电力系统保护和控制的设备，设计用于配电网络中的馈线保护。该继电器具有先进的保护功能、灵活的通信能力和高可靠性，广泛应用于各种配电系统中。
主要应用领域
配电网络保护
- 适用于电力公司的配电网络，提供线路保护和故障隔离。
- 用于中低压配电线路的保护，确保供电的连续性和安全性。
工业电力系统
- 在工业企业的电力系统中应用，保护关键负载和设备。
- 适用于制造业、石油化工、钢铁、矿业等行业的电力保护。
智能电网
- 在智能电网系统中，用于智能化的配电保护和监控。
- 提供数据采集和远程监控功能，支持电网的智能化管理。
分布式能源系统
- 适用于风电、光伏等分布式能源系统，提供保护和控制功能。
- 确保分布式能源系统的稳定运行和安全并网。
主要特点
全面的保护功能
- 过流保护：包括瞬时、定时限、反时限过流保护。
- 接地故障保护：快速检测并响应接地故障。
- 负序电流保护：检测和保护不平衡电流故障。
- 断路器失灵保护：检测断路器故障并进行后备保护。
先进的监控和测量
- 实时监测电流、电压、功率、频率等参数。
- 提供故障录波和事件记录功能，帮助故障分析和排除。
- 显示和记录谐波、电能质量等高级测量数据。
灵活的通信功能
- 支持多种通信协议，如Modbus、DNP3、IEC 61850等。
- 提供以太网、RS485、RS232等多种接口，支持远程监控和数据传输。
- 集成SCADA系统，实现全面的配电网络管理。
用户友好的界面
- 配备LCD显示屏和按键，方便现场操作和设置。
- 支持基于PC的软件工具，便于远程配置和维护。
高可靠性和环境适应性
- 设计坚固耐用，适应各种工业和户外环境。
- 提供抗电磁干扰、防尘、防水等多种防护功能。
英文资料：
MULTILIN MIFPI111E100H00 digital feed relay is a device used for power system protection and control, designed for feeder protection in distribution networks. This relay has advanced protection functions, flexible communication capabilities, and high reliability, and is widely used in various distribution systems.
Main application areas
Distribution network protection
Suitable for the distribution network of power companies, providing line protection and fault isolation.
Used for the protection of medium and low voltage distribution lines, ensuring the continuity and safety of power supply.
Industrial power system
Applied in the power system of industrial enterprises to protect critical loads and equipment.
Suitable for power protection in industries such as manufacturing, petrochemicals, steel, and mining.
Smart grid
In smart grid systems, it is used for intelligent distribution protection and monitoring.
Provide data collection and remote monitoring functions to support intelligent management of the power grid.
Distributed Energy System
Suitable for distributed energy systems such as wind power and photovoltaics, providing protection and control functions.
Ensure the stable operation and safe grid connection of distributed energy systems.
main features
Comprehensive protection function
Overcurrent protection: including instantaneous, timed, and inverse time overcurrent protection.
Ground fault protection: Quickly detect and respond to ground faults.
Negative sequence current protection: detects and protects against unbalanced current faults.
Circuit breaker failure protection: detect circuit breaker faults and provide backup protection.
Advanced monitoring and measurement
Real time monitoring of parameters such as current, voltage, power, frequency, etc.
Provide fault recording and event recording functions to assist in fault analysis and troubleshooting.
Display and record advanced measurement data such as harmonics and power quality.
Flexible communication capabilities
Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, etc.
Provide multiple interfaces such as Ethernet, RS485, RS232, etc., supporting remote monitoring and data transmission.
Integrate SCADA system to achieve comprehensive distribution network management.
User friendly interface
Equipped with an LCD display screen and buttons for easy on-site operation and setup.
Support PC based software tools for remote configuration and maintenance.
High reliability and environmental adaptability
Designed to be sturdy and durable, suitable for various industrial and outdoor environments.
Provide multiple protective functions such as anti electromagnetic interference, dust prevention, and waterproofing.
2.产 品 展 示
