Multilin 369-HI-0-M-F-0电机管理继电器 PDF资料
1.产 品 资 料 介 绍:
中文资料:
Multilin 369-HI-0-M-F-0电机管理继电器是一款专门用于保护和管理中低压电动机的先进设备。它提供全面的电机保护、监测和控制功能,广泛应用于各种工业环境,确保电动机的可靠性和效率。
主要应用领域
工业电机保护
- 适用于各种工业电动机,包括泵、风机、压缩机和传送带等。
- 提供过载、过热、短路和接地故障保护,确保电动机的安全运行。
过程控制系统
- 集成在过程控制系统中,实现电动机的自动化控制和保护。
- 适用于石油化工、钢铁、造纸等行业的过程控制系统。
水处理和废水处理
- 保护水处理和废水处理设施中的电动机,防止因故障导致的停机和损坏。
- 提供实时监测和诊断功能,提高系统的可靠性和效率。
矿业和金属加工
- 适用于矿业和金属加工行业中的大型电动机保护。
- 提供综合的保护和监测功能,确保设备的长时间稳定运行。
HVAC系统
- 在暖通空调系统中保护和管理电动机,确保系统高效运行。
- 提供综合保护功能,防止因电动机故障导致的系统停机。
主要特点
全面的保护功能
- 过载保护:防止电动机因过载而损坏。
- 温度保护:通过热敏电阻监测电动机温度,提供过热保护。
- 短路保护:快速检测和响应短路故障。
- 接地故障保护:检测并隔离接地故障,防止设备损坏。
- 失速保护:防止电动机在负载突变或其他异常情况下失速。
高级监测和诊断
- 实时监测电动机的运行状态和参数,如电流、电压、功率和温度。
- 提供故障诊断和报警功能,帮助维护人员快速识别和解决问题。
- 数据记录和事件日志:详细记录运行数据和事件,便于分析和维护。
灵活的通信功能
- 支持多种通信协议,如Modbus、DNP3等,便于集成到现有的自动化系统中。
- 提供以太网和串行接口,支持远程监控和数据传输。
用户友好的界面
- 配备LCD显示屏和按键,便于现场设置和操作。
- 提供基于PC的软件工具,支持远程配置和监控。
坚固耐用
- 设计坚固耐用,适用于恶劣的工业环境。
- 提供长时间可靠运行,减少维护成本和停机时间。
英文资料:
The Multilin 369-HI-0-M-F-0 motor management relay is an advanced device specifically designed to protect and manage medium and low voltage motors. It provides comprehensive motor protection, monitoring, and control functions, widely used in various industrial environments to ensure the reliability and efficiency of electric motors.
Main application areas
Industrial motor protection
Suitable for various industrial motors, including pumps, fans, compressors, and conveyor belts.
Provide overload, overheating, short circuit, and ground fault protection to ensure the safe operation of the motor.
process control system
Integrated into the process control system to achieve automated control and protection of electric motors.
Process control systems suitable for industries such as petrochemicals, steel, and papermaking.
Water treatment and wastewater treatment
Protect the electric motors in water and wastewater treatment facilities to prevent downtime and damage caused by malfunctions.
Provide real-time monitoring and diagnostic functions to improve the reliability and efficiency of the system.
Mining and metal processing
Suitable for the protection of large electric motors in the mining and metal processing industries.
Provide comprehensive protection and monitoring functions to ensure the long-term stable operation of the equipment.
HVAC system
Protect and manage electric motors in HVAC systems to ensure efficient operation of the system.
Provide comprehensive protection function to prevent system shutdown caused by motor failure.
main features
Comprehensive protection function
Overload protection: prevents the motor from being damaged due to overload.
Temperature protection: Monitor the temperature of the motor through a thermistor to provide overheating protection.
Short circuit protection: Quickly detect and respond to short circuit faults.
Ground fault protection: detect and isolate ground faults to prevent equipment damage.
Stall protection: prevents the motor from stalling in case of sudden load changes or other abnormal situations.
Advanced monitoring and diagnosis
Real time monitoring of the operating status and parameters of the electric motor, such as current, voltage, power, and temperature.
Provide fault diagnosis and alarm functions to help maintenance personnel quickly identify and solve problems.
Data recording and event logs: Detailed recording of operational data and events for easy analysis and maintenance.
Flexible communication capabilities
Supports multiple communication protocols such as Modbus, DNP3, etc., making it easy to integrate into existing automation systems.
Provide Ethernet and serial interfaces, supporting remote monitoring and data transmission.
User friendly interface
Equipped with an LCD display screen and buttons for easy on-site setup and operation.
Provide PC based software tools that support remote configuration and monitoring.
durable
Designed to be sturdy and durable, suitable for harsh industrial environments.
Provide long-term reliable operation, reduce maintenance costs and downtime.
2.产 品 展 示
