70PR05B-ES线路接口模块,70PR05B-ES英文说明
通过IMHSS03面板可以看到九个LED。
顶部LED（红色/绿色）指示通信状态HSS模块和多功能处理器模块之间，以及整体状态（见图5-1）。接下来的八个LED（标记为1到8）用于诊断目的。
LED 1、4和8在正常操作期间用于指示参数/校准、输出的自动调谐禁用和硬手动模式。
70PR05B-ES线路接口模块表5-1列出了LED各种操作条件的状态。在诊断模式下，八个红色LED指示通过/失败计数或测试编号和状态（通过/失败）。图6-1显示了诊断LED显示屏。IMHSS03模块固件包含诊断例程
可以在通电时调用。诊断例行程序允许验证模块组件和电路。
当模块处于诊断模式时，它无法执行IMHSS03模块的功能。因此，诊断应在离线的模块上使用。
There are nine LEDs visible through the IMHSS03 faceplate.
The top LED (red/green) indicates communication status
between the HSS module and multi-function processor module, and overall status (see Figure 5-1). The next eight LEDs
(labeled one through eight) are used for diagnostic purposes.
LEDs one, four and eight are used during normal operation to
indicate automatic tuning of parameters/calibration, outputs
disabled and hard manual mode. Table 5-1 lists the LED
states for various operating conditions. In diagnostics mode,
the eight red LEDs indicate either pass/fail count or test number and status (pass/fail). Figure 6-1 shows the diagnostic
LED display.The IMHSS03 module firmware contains diagnostic routines
that can be invoked from power up. The diagnostic routines
allow verification of the module components and circuitry.
When the module is in diagnostic mode, it cannot perform the
functions of an IMHSS03 module. Therefore, diagnostics
should be used on modules that are off-line.
