Multilin 750-P1-G1-S1-H电源管理 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Multilin 750-P1-G1-S1-H 是 GE Multilin 提供的一款电源管理系统，旨在优化和保护电力系统中的电源分配。此系统提供了全面的电源监控、保护和控制功能，适用于各种工业和商业电力应用。以下是 Multilin 750-P1-G1-S1-H 电源管理系统的主要特点和应用领域：
主要特点：
电源监控：
- 实时数据：提供实时的电压、电流、功率和功率因数等电源参数监控，帮助用户了解电力系统的运行状态。
- 电能质量分析：监测和分析电能质量，包括谐波、闪变、频率波动等，确保电力系统的稳定性。
保护功能：
- 过载保护：在电流超出设定值时自动切断电源，防止电气设备过载。
- 短路保护：提供短路故障检测和断路功能，确保系统在发生短路时能够迅速断开电源。
- 欠电压和过电压保护：监控电压水平，并在出现欠电压或过电压情况时触发警报或断开电源。
控制功能：
- 开关控制：能够远程控制电源开关，方便进行系统切换和故障排查。
- 自动重启：在系统恢复正常后自动重启，减少人工干预的需求。
通信能力：
- 通讯协议支持：支持常见的通讯协议，如 Modbus、DNP3、Ethernet/IP 等，方便与其他监控和控制系统的集成。
- 远程监控：提供远程访问功能，通过网络接口实现数据监控和系统控制。
用户界面：
- 显示屏：配备显示屏，显示电源参数、状态信息和故障报警，便于现场操作和数据查看。
- 操作简便：用户界面设计直观，易于配置和操作，提供快捷的设置和调整选项。
高可靠性：
- 工业级设计：设计用于工业环境，具备高可靠性和耐用性，能够在各种工作条件下稳定运行。
- 抗干扰能力：具有良好的抗电磁干扰能力，确保测量数据和系统操作的准确性。
数据记录与分析：
- 历史数据记录：能够存储历史数据和事件日志，支持后续分析和报告生成。
- 故障诊断：提供详细的故障记录和诊断功能，帮助识别和排除电力系统中的问题。
英文资料：
Multilin 750-P1-G1-S1-H is a power management system provided by GE Multilin, designed to optimize and protect power distribution in the power system. This system provides comprehensive power monitoring, protection, and control functions, suitable for various industrial and commercial power applications. The following are the main features and application areas of the Multilin 750-P1-G1-S1-H power management system:
Main features:
Power monitoring:
Real time data: Provides real-time monitoring of power parameters such as voltage, current, power, and power factor to help users understand the operating status of the power system.
Power quality analysis: Monitor and analyze power quality, including harmonics, flicker, frequency fluctuations, etc., to ensure the stability of the power system.
Protection function:
Overload protection: Automatically cuts off the power supply when the current exceeds the set value to prevent electrical equipment from overloading.
Short circuit protection: Provides short circuit fault detection and circuit breaking functions to ensure that the system can quickly disconnect the power supply in the event of a short circuit.
Undervoltage and Overvoltage Protection: Monitor voltage levels and trigger alarms or disconnect power in the event of undervoltage or overvoltage conditions.
Control function:
Switch control: It can remotely control the power switch, facilitating system switching and troubleshooting.
Automatic restart: Automatically restart after the system returns to normal, reducing the need for manual intervention.
Communication ability:
Communication protocol support: Supports common communication protocols such as Modbus, DNP3, Ethernet/IP, etc., facilitating integration with other monitoring and control systems.
Remote monitoring: Provides remote access functionality, enabling data monitoring and system control through network interfaces.
User interface:
Display screen: Equipped with a display screen, it displays power parameters, status information, and fault alarms for easy on-site operation and data viewing.
Easy to operate: The user interface design is intuitive, easy to configure and operate, and provides quick settings and adjustment options.
High reliability:
Industrial grade design: designed for industrial environments, with high reliability and durability, capable of stable operation under various working conditions.
Anti interference ability: It has good anti electromagnetic interference ability to ensure the accuracy of measurement data and system operation.
Data recording and analysis:
Historical data recording: capable of storing historical data and event logs, supporting subsequent analysis and report generation.
Fault diagnosis: Provide detailed fault records and diagnostic functions to help identify and troubleshoot problems in the power system.
2.产 品 展 示
