Multilin UR8FH多芯UR模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Multilin UR8FH 是 GE 的 Multilin UR 系列中的一款多功能保护和控制模块，通常用于电力系统中的保护和监控。以下是关于 Multilin UR8FH 多芯 UR 模块的详细信息：
主要特性和功能
保护功能：
- 过电流保护： 实时监测电流，并在检测到过电流时提供保护。
- 地漏电流保护： 检测地漏电流，防止因绝缘故障引起的问题。
- 断相保护： 检测电源缺相或不平衡情况，防止因缺相对系统造成的损坏。
- 过电压/欠电压保护： 监控电压波动，提供保护以防止电压异常对系统的影响。
- 短路保护： 提供短路保护，防止因短路引起的设备损坏和安全问题。
监控与诊断：
- 实时监控： 提供实时电流、电压、功率等关键参数的监控。
- 故障诊断： 记录故障事件并提供详细诊断信息，帮助快速定位和解决问题。
- 数据记录： 存储历史数据和事件记录，便于后续分析和审计。
通信与集成：
- 通信协议： 支持多种工业标准通信协议，如 Modbus、DNP3、IEC 61850，便于与其他控制系统集成。
- 远程监控： 通过网络接口支持远程访问、配置和监控，增强系统管理的便利性。
用户界面：
- 显示屏： 配备 LCD 显示屏，用于实时显示保护参数和系统状态。
- 操作界面： 提供用户友好的界面，方便设置和调整。
灵活配置：
- 提供多种输入/输出选项，可根据具体应用需求进行配置，确保系统的灵活性和可扩展性。
英文资料：
Multilin UR8FH is a multifunctional protection and control module in GE's Multilin UR series, commonly used for protection and monitoring in power systems. The following is detailed information about the Multilin UR8FH multi-core UR module:
Main features and functions
Protection function:
Overcurrent protection: Real time monitoring of current and providing protection when overcurrent is detected.
Ground leakage current protection: Detect ground leakage current to prevent problems caused by insulation faults.
Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the system caused by phase loss.
Overvoltage/undervoltage protection: Monitor voltage fluctuations and provide protection to prevent abnormal voltage from affecting the system.
Short circuit protection: Provides short circuit protection to prevent equipment damage and safety issues caused by short circuits.
Monitoring and Diagnosis:
Real time monitoring: Provides real-time monitoring of key parameters such as current, voltage, and power.
Fault diagnosis: Record fault events and provide detailed diagnostic information to help quickly locate and solve problems.
Data recording: Store historical data and event records for subsequent analysis and auditing.
Communication and Integration:
Communication Protocol: Supports multiple industrial standard communication protocols, such as Modbus, DNP3, IEC 61850, for easy integration with other control systems.
Remote monitoring: Supports remote access, configuration, and monitoring through network interfaces, enhancing the convenience of system management.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of protection parameters and system status.
Operation interface: Provides a user-friendly interface for easy setting and adjustment.
Flexible configuration:
Provide multiple input/output options that can be configured according to specific application requirements, ensuring the flexibility and scalability of the system.
application area
Power system: used for protection and control in the power distribution system, ensuring the stability and safety of the power system.
Industrial automation: Used for equipment protection and monitoring in industrial environments, supporting automation control systems.
Power generation and substations: suitable for protection and control in generator sets and substations.
2.产 品 展 示
