MULTILIN GEHDACAB电机管理器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Multilin GEHDACAB 电机管理器是 GE 的 Multilin 系列中的一款高级电机保护和管理设备，专为电机提供全面的保护、监控和控制功能。以下是关于 Multilin GEHDACAB 电机管理器的详细信息：
主要特性和功能
电机保护功能：
- 过载保护： 实时监测电机的电流，防止过载情况导致的电机损坏。
- 堵转保护： 在电机启动和运行时检测堵转情况，并提供保护以防止电机损坏。
- 断相保护： 检测电源缺相或不平衡情况，防止因缺相对电机造成的损坏。
- 过电压/欠电压保护： 保护电机免受电压波动的影响。
- 短路保护： 检测异常电流情况，提供短路保护以防止电机受损。
- 热保护： 通过温度监测防止电机过热，保护电机的正常运行。
- 地漏电流保护： 监测并保护因绝缘故障引起的地漏电流问题。
监控与诊断：
- 实时监控： 提供实时的电流、电压、功率和其他关键参数的监控。
- 故障诊断： 记录故障事件并提供详细的诊断信息，帮助快速定位和解决问题。
- 数据记录： 存储历史数据和事件记录，便于后续分析和审计。
通信与集成：
- 通信协议： 支持多种工业标准通信协议，如 Modbus RTU、Modbus TCP/IP、DNP3 和 IEC 61850，便于与其他控制系统集成。
- 远程监控： 通过通信接口支持远程访问和监控，简化维护和管理工作。
用户界面：
- 显示屏： 配备 LCD 显示屏，用于实时显示电机的运行状态和参数。
- 操作界面： 友好的用户界面，方便进行设置和调整。
- 可编程性： 提供可编程的输入/输出选项，以满足特定应用需求。
扩展功能：
- 多种保护算法： 提供多种保护算法，适应不同类型电机的保护需求。
- 灵活配置： 可根据具体应用需求进行配置，确保系统的灵活性和可扩展性。
英文资料：
The Multilin GEHDACAB motor manager is an advanced motor protection and management device in GE's Multilin series, designed to provide comprehensive protection, monitoring, and control functions for motors. The following is detailed information about the Multilin GEHDACAB motor manager:
Main features and functions
Motor protection function:
Overload protection: Real time monitoring of motor current to prevent motor damage caused by overload situations.
Blocked rotor protection: Detect the situation of blocked rotor during motor start-up and operation, and provide protection to prevent motor damage.
Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the motor caused by phase loss.
Overvoltage/undervoltage protection: protects the motor from voltage fluctuations.
Short circuit protection: detects abnormal current conditions and provides short circuit protection to prevent motor damage.
Thermal protection: Prevent motor overheating through temperature monitoring and ensure the normal operation of the motor.
Ground leakage current protection: Monitor and protect against ground leakage current issues caused by insulation faults.
Monitoring and Diagnosis:
Real time monitoring: Provides real-time monitoring of current, voltage, power, and other key parameters.
Fault diagnosis: Record fault events and provide detailed diagnostic information to help quickly locate and solve problems.
Data recording: Store historical data and event records for subsequent analysis and auditing.
Communication and Integration:
Communication Protocol: Supports multiple industrial standard communication protocols, such as Modbus RTU, Modbus TCP/IP, DNP3, and IEC 61850, making it easy to integrate with other control systems.
Remote monitoring: Supports remote access and monitoring through communication interfaces, simplifying maintenance and management work.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of the motor's operating status and parameters.
Operating Interface: A user-friendly interface that facilitates settings and adjustments.
Programmable: Provides programmable input/output options to meet specific application requirements.
Extended functions:
Multiple protection algorithms: Provide multiple protection algorithms to meet the protection needs of different types of motors.
Flexible configuration: It can be configured according to specific application requirements to ensure the flexibility and scalability of the system.
2.产 品 展 示
