MULTILIN EP5P5B5HRR电机保护系统 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ultilin EP5P5B5HRR 是 GE 的 Multilin 系列中的一款电机保护系统，旨在为电机提供全面的保护和控制功能。以下是关于 Multilin EP5P5B5HRR 电机保护系统的详细信息：
主要特性和功能
电机保护功能：
- 过载保护： 实时监控电机的电流，防止过载情况导致的电机损坏。
- 堵转保护： 检测电机启动时的堵转情况，提供保护以防止电机损坏。
- 断相保护： 检测电源缺相或不平衡情况，防止因缺相对电机造成的损坏。
- 过电压/欠电压保护： 保护电机免受电压波动的影响。
- 短路保护： 监测异常电流情况，提供短路保护以防止电机受损。
- 热保护： 通过温度监测防止电机过热，保护电机的正常运行。
- 地漏电流保护： 监测并保护因绝缘故障引起的地漏电流问题。
监控与诊断：
- 实时监控： 提供实时的电流、电压、功率和其他关键参数的监控。
- 故障诊断： 记录故障事件并提供详细的诊断信息，帮助快速定位和解决问题。
- 数据记录： 存储历史数据和事件记录，便于后续分析和审计。
通信与集成：
- 通信协议： 支持多种工业标准通信协议，如 Modbus RTU、Modbus TCP/IP、DNP3 和 IEC 61850，便于与其他控制系统集成。
- 远程监控： 通过通信接口支持远程访问和监控，简化维护和管理工作。
用户界面：
- 显示屏： 配备 LCD 显示屏，用于实时显示电机的运行状态和参数。
- 操作界面： 友好的用户界面，方便进行设置和调整。
- 可编程性： 提供可编程的输入/输出选项，以满足特定应用需求。
扩展功能：
- 多种保护算法： 提供多种保护算法，适应不同类型电机的保护需求。
- 灵活配置： 可根据具体应用需求进行配置，确保系统的灵活性和可扩展性。
应用领域
- 工业自动化： 在各种工业环境中用于电机的保护和控制，确保设备的可靠运行。
- 发电和配电系统： 适用于发电机组和配电系统中的电机保护和监控。
- 水处理和泵站： 用于水处理设施和泵站中的电机保护，防止因故障导致的设备停机和损坏。
英文资料：
The ultilin EP5P5B5HRR is a motor protection system in GE's Multilin series, designed to provide comprehensive protection and control functions for motors. The following is detailed information about the Multilin EP5P5B5HRR motor protection system:
Main features and functions
Motor protection function:
Overload protection: Real time monitoring of motor current to prevent motor damage caused by overload situations.
Blocked rotor protection: detects the blockage of the motor during startup and provides protection to prevent motor damage.
Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the motor caused by phase loss.
Overvoltage/undervoltage protection: protects the motor from voltage fluctuations.
Short circuit protection: Monitor abnormal current conditions and provide short circuit protection to prevent motor damage.
Thermal protection: Prevent motor overheating through temperature monitoring and ensure the normal operation of the motor.
Ground leakage current protection: Monitor and protect against ground leakage current issues caused by insulation faults.
Monitoring and Diagnosis:
Real time monitoring: Provides real-time monitoring of current, voltage, power, and other key parameters.
Fault diagnosis: Record fault events and provide detailed diagnostic information to help quickly locate and solve problems.
Data recording: Store historical data and event records for subsequent analysis and auditing.
Communication and Integration:
Communication Protocol: Supports multiple industrial standard communication protocols, such as Modbus RTU, Modbus TCP/IP, DNP3, and IEC 61850, making it easy to integrate with other control systems.
Remote monitoring: Supports remote access and monitoring through communication interfaces, simplifying maintenance and management work.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of the motor's operating status and parameters.
Operating Interface: A user-friendly interface that facilitates settings and adjustments.
Programmable: Provides programmable input/output options to meet specific application requirements.
Extended functions:
Multiple protection algorithms: Provide multiple protection algorithms to meet the protection needs of different types of motors.
Flexible configuration: It can be configured according to specific application requirements to ensure the flexibility and scalability of the system.
application area
Industrial automation: Used for motor protection and control in various industrial environments to ensure reliable operation of equipment.
Power generation and distribution system: suitable for motor protection and monitoring in generator sets and distribution systems.
Water treatment and pumping stations: used for motor protection in water treatment facilities and pumping stations to prevent equipment shutdown and damage caused by malfunctions.
2.产 品 展 示
