MULTILIN F650BABF1G0LO馈线保护继电器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
MULTILIN F650BABF1G0LO 是 GE 的 MULTILIN 系列中的一款馈线保护继电器，设计用于电力系统中的馈线保护和控制。以下是关于 F650BABF1G0LO 的详细信息，包括其主要特性和应用领域：
主要特性和功能
保护功能：
- 过电流保护： 监测馈线的电流，提供过电流保护以防止过载和短路。
- 地漏电流保护： 监测地漏电流，防止由于绝缘故障导致的系统问题。
- 断相保护： 检测电源缺相或不平衡，防止因缺相对馈线造成的损害。
- 过电压/欠电压保护： 保护馈线免受电压异常的影响。
监控与诊断：
- 实时监控： 提供实时的电流、电压、功率等参数显示，便于监控馈线的运行状态。
- 故障记录： 存储故障事件和历史数据，帮助分析和诊断系统问题。
- 性能分析： 提供详细的系统性能数据，支持预防性维护和优化操作。
通信与集成：
- 通信协议： 支持常见的工业通信协议，如 Modbus、DNP3、IEC 61850，便于与其他控制系统集成。
- 远程监控： 通过网络接口支持远程访问、配置和监控，增强系统管理的便利性。
用户界面：
- 显示屏： 配备 LCD 显示屏，用于实时显示保护参数和系统状态。
- 操作界面： 提供用户友好的界面，方便设置和调整保护功能。
应用领域：
- 电力系统： 用于电力配电系统中的馈线保护，确保电力系统的稳定性和安全性。
- 工业自动化： 在工业环境中为馈线提供保护和监控，支持自动化控制系统。
- 发电和变电站： 适用于发电机组和变电站中的馈线保护和控制。
英文资料：
MULTILIN F650BABF1G0LO is a feeder protection relay in GE's MULTILIN series, designed for feeder protection and control in power systems. The following is detailed information about F650BABF1G0LO, including its main features and application areas:
Main features and functions
Protection function:
Overcurrent protection: Monitor the current of the feeder and provide overcurrent protection to prevent overload and short circuit.
Ground leakage current protection: Monitor ground leakage current to prevent system problems caused by insulation faults.
Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the feeder caused by phase loss.
Overvoltage/undervoltage protection: protects the feeder from the impact of abnormal voltage.
Monitoring and Diagnosis:
Real time monitoring: Provides real-time display of parameters such as current, voltage, and power, making it easy to monitor the operating status of feeders.
Fault records: Store fault events and historical data to assist in analyzing and diagnosing system issues.
Performance analysis: Provide detailed system performance data to support preventive maintenance and optimization operations.
Communication and Integration:
Communication Protocol: Supports common industrial communication protocols such as Modbus, DNP3, IEC 61850, making it easy to integrate with other control systems.
Remote monitoring: Supports remote access, configuration, and monitoring through network interfaces, enhancing the convenience of system management.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of protection parameters and system status.
Operation interface: Provides a user-friendly interface for easy setting and adjustment of protection functions.
Application areas:
Power system: used for feeder protection in power distribution systems to ensure the stability and safety of the power system.
Industrial automation: providing protection and monitoring for feeders in industrial environments, supporting automation control systems.
Power generation and substations: suitable for feeder protection and control in generator sets and substations.
2.产 品 展 示
