Multilin F60C00HCHF8AH6继电器面板
1.产 品 资 料 介 绍：
中文资料：
Multilin F60C00HCHF8AH6 继电器面板是 GE Multilin 系列的一部分，专为配电和变电站应用设计，提供全面的馈线保护和控制功能。该继电器面板具备多种保护、监测和控制功能，适用于各种电力系统环境。
主要功能和特点
馈线保护
- 过流保护：提供瞬时、定时限和反时限过流保护，确保在故障情况下快速响应并隔离故障。
- 接地保护：具备接地故障保护功能，监测和保护接地故障，防止设备损坏和停电事故。
电压保护
- 过压和欠压保护：保护系统免受电压异常影响，确保设备和系统的稳定运行。
- 零序电压保护：用于检测和保护接地故障，提供额外的保护层。
频率保护
- 频率过高和过低保护：监测系统频率，防止频率异常引起的系统不稳定和设备损坏。
断路器控制
- 自动重合闸功能：在故障清除后，自动重合闸功能可提高系统的供电可靠性。
- 断路器失灵保护：检测断路器失灵情况，并迅速采取措施隔离故障区域。
通信和接口
- 多种通信协议：支持 Modbus、DNP3、IEC 61850 等通信协议，确保与其他系统的兼容性。
- 标准接口：提供以太网、RS-232 和 RS-485 接口，便于与外部设备和系统进行数据交换。
数据记录和事件分析
- 故障记录：记录故障事件的详细信息，便于事后分析和故障排查。
- 事件日志和波形捕捉：捕捉事件发生时的电气波形，帮助用户进行深入的事件分析和诊断。
用户界面和配置
- 直观的 LCD 显示屏：配备直观的显示屏，用户可以轻松查看和设置参数。
- 图形化配置工具：通过图形化配置工具，用户可以简化配置过程，提高工作效率。
- 远程配置和监控：支持远程配置和监控功能，方便集中管理和维护。
高可靠性和环境适应性
- 工业级设计：具备高可靠性的设计，能够适应各种严苛的工作环境。
- 宽温范围运行：能够在广泛的温度范围内稳定运行，确保系统的可靠性。
应用领域
变电站
- 主变压器保护：为变电站中的主变压器提供全面的保护，防止故障影响系统稳定。
- 母线保护：监测和保护变电站中的母线，防止故障扩大，保障电力系统的稳定性。
输配电系统
- 线路保护：为输电线路提供高效的保护，防止故障引发大范围停电。
- 分段保护：对配电系统中的各个分段进行保护和控制，提高配电网络的可靠性。
工业电力系统
- 设备保护：保护工业电力系统中的关键设备，防止因故障导致的生产中断。
- 电网稳定性：通过提供全面的保护功能，确保工业电力系统的稳定运行。
总结
Multilin F60C00HCHF8AH6 继电器面板提供了先进的馈线保护、电压保护、频率保护和断路器控制功能，适用于变电站、输配电系统和工业电力系统中的关键设备保护。其高灵敏度、高可靠性和丰富的通信接口，使其成为电力保护和控制系统中的重要组成部分。
英文资料：
The Multilin F60C00HCHFAH6 relay panel is part of the GE Multilin series, designed specifically for distribution and substation applications, providing comprehensive feeder protection and control functions. This relay panel has multiple protection, monitoring, and control functions, suitable for various power system environments.
Main functions and features
feeder protection
Overcurrent protection: Provides instantaneous, timed, and inverse time overcurrent protection to ensure rapid response and isolation of faults in the event of a malfunction.
Grounding protection: equipped with grounding fault protection function, monitoring and protecting grounding faults, preventing equipment damage and power outage accidents.
Voltage protection
Overvoltage and undervoltage protection: protects the system from abnormal voltage effects and ensures stable operation of equipment and systems.
Zero sequence voltage protection: used to detect and protect ground faults, providing additional protection layer.
Frequency protection
High and low frequency protection: Monitor the system frequency to prevent system instability and equipment damage caused by abnormal frequency.
Circuit breaker control
Automatic reclosing function: After the fault is cleared, the automatic reclosing function can improve the power supply reliability of the system.
Circuit breaker failure protection: detect circuit breaker failure and quickly take measures to isolate the faulty area.
Communication and Interface
Multiple communication protocols: Supports communication protocols such as Modbus, DNP3, IEC 61850, etc., ensuring compatibility with other systems.
Standard interface: Provides Ethernet, RS-232, and RS-485 interfaces for easy data exchange with external devices and systems.
Data recording and event analysis
Fault record: Record detailed information of fault events for post analysis and troubleshooting.
Event logs and waveform capture: Capture the electrical waveform at the time of an event to assist users in conducting in-depth event analysis and diagnosis.
User interface and configuration
Intuitive LCD display: Equipped with an intuitive display screen, users can easily view and set parameters.
Graphical configuration tool: Through graphical configuration tools, users can simplify the configuration process and improve work efficiency.
Remote configuration and monitoring: Supports remote configuration and monitoring functions, facilitating centralized management and maintenance.
High reliability and environmental adaptability
Industrial grade design: With high reliability design, it can adapt to various harsh working environments.
Wide temperature range operation: capable of stable operation over a wide temperature range, ensuring the reliability of the system.
application area
transformer substation
Main transformer protection: provides comprehensive protection for the main transformers in the substation to prevent faults from affecting system stability.
Busbar protection: Monitor and protect the busbars in substations to prevent the expansion of faults and ensure the stability of the power system.
Power transmission and distribution system
Line protection: provides efficient protection for transmission lines to prevent widespread power outages caused by faults.
Segmented protection: Protecting and controlling each segment in the distribution system to improve the reliability of the distribution network.
Industrial power system
Equipment protection: Protecting critical equipment in industrial power systems to prevent production interruptions caused by malfunctions.
Grid stability: By providing comprehensive protection functions, ensure the stable operation of industrial power systems.
summary
The Multilin F60C00HCHFAH6 relay panel provides advanced feeder protection, voltage protection, frequency protection, and circuit breaker control functions, suitable for key equipment protection in substations, transmission and distribution systems, and industrial power systems. Its high sensitivity, high reliability, and rich communication interfaces make it an important component of power protection and control systems.
2.产 品 展 示
3.其他产品
BENTLY 350022M 138607-01系统模块卡件
216AB61 HESG324013R101 Digital control module
216EA61B HESG448230R1/G ABB digital input module
ABB UNIROL1010 3BHE035301R0001 Excitation controller
