MULTILIN 369-HI-0-M-0-E电机管理继电器
1.产 品 资 料 介 绍：
中文资料：
GE Multilin 369-HI-0-M-0-E 是一款高性能的电机管理继电器，设计用于提供电机保护、监控和控制。它集成了多种保护功能，适用于各种电力系统和工业应用。以下是该继电器的详细信息：
产品概述
- 型号：369-HI-0-M-0-E
- 产品类型：电机管理继电器
主要特点
- 多功能保护：集成了多种电机保护功能，如过载保护、堵转保护、热保护、欠压保护、过压保护等。
- 高级控制功能：支持自动重启、逻辑控制、延时操作等功能，提供灵活的电机控制方案。
- 实时监控：能够实时监控电机的运行状态和性能，包括电流、电压、功率等参数。
- 用户界面：配备直观的图形用户界面（GUI），便于配置、操作和监控。
- 通信能力：支持多种通信协议（如Modbus、DNP3、IEC 61850），方便与其他设备和系统集成。
技术规格
- 型号：369-HI-0-M-0-E
- 保护功能：
- 过载保护：检测电机负载超出预设值的情况，并触发保护措施。
- 堵转保护：防止电机在堵转状态下运行，减少设备损坏风险。
- 热保护：监测电机温度，防止过热。
- 欠压保护：防止电机在欠压条件下运行，确保设备安全。
- 过压保护：防止电机在过压条件下运行，保证系统稳定。
- 控制功能：包括自动重启、延时操作、逻辑控制等，适应多种控制需求。
- 数据采集：支持电流、电压、功率因数等参数的实时采集和分析。
- 显示与界面：高分辨率显示屏和用户友好的操作界面。
- 通讯接口：支持多种通信协议，如Modbus、DNP3、IEC 61850。
- 环境温度：通常适应0°C到50°C的工作温度范围。
- 安装方式：支持面板安装或DIN导轨安装。
应用领域
- 电机保护：用于电力系统中的电机保护，确保其安全稳定运行。
- 工业自动化：提供电机保护和控制功能，适用于工业自动化系统。
- 建筑电力管理：适用于建筑物内的电机保护和管理，防止设备损坏。
- 能源管理：提供详细的电机运行数据和保护功能，帮助优化能源使用。
安装与维护
- 安装：设备通常通过面板或DIN导轨安装，具体方式请参考产品手册。
- 维护：设计简洁，便于日常维护和检查。建议定期检查设备状态和连接线，以确保正常运行。
优势
- 全面保护：集成多种保护功能，确保电机的安全运行。
- 灵活控制：提供多种控制选项，适应不同的应用需求。
- 强大通信能力：支持多种通信协议，便于与其他设备和系统集成。
- 用户友好：直观的用户界面和功能，简化操作和配置过程。
总结
GE Multilin 369-HI-0-M-0-E 电机管理继电器是一款高性能的保护和控制设备，专为电机管理设计。其综合的保护功能、高级控制能力和强大的通信能力使其成为各种电力和工业应用中的理想选择。
英文资料：
GE Multilin 369-HI-0-M-0-E is a high-performance motor management relay designed to provide motor protection, monitoring, and control. It integrates multiple protection functions and is suitable for various power systems and industrial applications. The following is the detailed information of the relay:
Product Overview
Model: 369-HI-0-M-0-E
Product Type: Motor Management Relay
main features
Multi functional protection: It integrates multiple motor protection functions, such as overload protection, locked rotor protection, thermal protection, undervoltage protection, overvoltage protection, etc.
Advanced control function: supports automatic restart, logic control, delayed operation and other functions, providing flexible motor control solutions.
Real time monitoring: It can monitor the operating status and performance of the motor in real time, including parameters such as current, voltage, and power.
User Interface: Equipped with an intuitive graphical user interface (GUI) for easy configuration, operation, and monitoring.
Communication capability: Supports multiple communication protocols (such as Modbus DNP3、IEC 61850）， Facilitate integration with other devices and systems.
technical specifications
Model: 369-HI-0-M-0-E
Protection function:
Overload protection: detects the situation where the motor load exceeds the preset value and triggers protective measures.
Locking protection: prevents the motor from running in a locked state, reducing the risk of equipment damage.
Thermal protection: Monitor motor temperature to prevent overheating.
Undervoltage protection: prevents the motor from operating under undervoltage conditions, ensuring equipment safety.
Overvoltage protection: prevents the motor from operating under overvoltage conditions, ensuring system stability.
Control functions: including automatic restart, delayed operation, logic control, etc., suitable for various control needs.
Data collection: supports real-time collection and analysis of parameters such as current, voltage, and power factor.
Display and Interface: High resolution display screen and user-friendly interface.
Communication interface: Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850.
Environmental temperature: typically suitable for a working temperature range of 0 ° C to 50 ° C.
Installation method: Supports panel installation or DIN rail installation.
application area
Motor protection: used for motor protection in power systems to ensure their safe and stable operation.
Industrial Automation: Provides motor protection and control functions, suitable for industrial automation systems.
Building power management: applicable to the protection and management of motors inside buildings to prevent equipment damage.
Energy management: Provide detailed motor operation data and protection functions to help optimize energy use.
Installation and maintenance
Installation: The device is usually installed through a panel or DIN rail. Please refer to the product manual for specific instructions.
Maintenance: The design is simple and easy to maintain and inspect on a daily basis. It is recommended to regularly check the equipment status and connection wires to ensure normal operation.
advantage
Comprehensive protection: integrates multiple protection functions to ensure the safe operation of the motor.
Flexible control: Provides multiple control options to adapt to different application needs.
Powerful communication capability: Supports multiple communication protocols, making it easy to integrate with other devices and systems.
User friendly: intuitive user interface and functionality, simplifying the operation and configuration process.
summary
The GE Multilin 369-HI-0-M-0-E motor management relay is a high-performance protection and control device designed specifically for motor management. Its comprehensive protection functions, advanced control capabilities, and powerful communication capabilities make it an ideal choice for various power and industrial applications.
2.产 品 展 示
