1.产 品 资 料 介 绍：
中文资料：
GE Multilin 269PLUS-DO-311 是一款先进的电机管理继电器，专为电力系统中的电机保护和管理设计。它集成了多种功能，提供全面的电机保护、监控和控制。以下是该继电器的详细信息：
产品概述
- 型号：269PLUS-DO-311
- 产品类型：电机管理继电器
主要特点
- 综合电机保护：提供全面的电机保护功能，包括过载保护、堵转保护、热保护、欠压保护、过压保护等。
- 实时监控：能够实时监控电机的运行状态和性能，包括电流、电压、功率因数等参数。
- 高精度测量：提供高精度的测量和保护功能，确保电机的安全和高效运行。
- 用户界面：配备直观的图形用户界面（GUI），便于用户配置、操作和监控。
- 通信能力：支持多种通信协议，如Modbus、DNP3、IEC 61850等，方便与其他设备和系统集成。
技术规格
- 型号：269PLUS-DO-311
- 保护功能：
- 过载保护：检测并响应电机负载超出设定值的情况。
- 堵转保护：防止电机在堵转状态下运行，减少损坏风险。
- 热保护：监测电机的温度，防止过热。
- 欠压保护：防止电机在欠压条件下运行，避免损坏。
- 过压保护：防止电机在过压条件下运行，确保系统稳定。
- 数据采集：支持电流、电压、功率因数等参数的实时采集和分析。
- 显示与界面：配备高分辨率显示屏和用户友好的操作界面。
- 通讯接口：支持多种通信协议，如Modbus、DNP3、IEC 61850等。
- 环境温度：通常适应0°C到50°C的工作温度范围。
- 安装方式：支持面板安装或DIN导轨安装。
应用领域
- 电机保护：用于保护电力系统中的电机，确保其安全运行。
- 工业自动化：在工业自动化系统中提供电机保护和管理功能。
- 建筑电力管理：适用于建筑物内的电机保护和控制，防止设备损坏。
安装与维护
- 安装：设备通常通过面板或DIN导轨安装，具体方式请参考产品手册。
- 维护：设计简洁，便于日常维护和检查。建议定期检查设备状态和连接线，确保正常运行。
优势
- 高性能保护：提供全面的电机保护功能，确保电机的安全和高效运行。
- 灵活性：支持多种保护功能和配置选项，适应不同的电机应用需求。
- 兼容性：支持多种通信协议，便于与其他设备和系统集成。
- 用户友好：配备直观的界面和功能，简化了操作和配置过程。
总结
GE Multilin 269PLUS-DO-311 电机管理继电器是一款高性能、功能全面的设备，专为电机保护和管理设计。其综合的保护功能、高精度测量和强大的通信能力使其成为电力系统和工业自动化应用中的理想选择。
英文资料：
GE Multilin 269PLUS-DO-311 is an advanced motor management relay designed specifically for motor protection and management in power systems. It integrates multiple functions, providing comprehensive motor protection, monitoring, and control. The following is the detailed information of the relay:
Product Overview
Model: 269PLUS-DO-311
Product Type: Motor Management Relay
main features
Comprehensive motor protection: Provides comprehensive motor protection functions, including overload protection, locked rotor protection, thermal protection, undervoltage protection, overvoltage protection, etc.
Real time monitoring: It can monitor the operating status and performance of the motor in real time, including parameters such as current, voltage, power factor, etc.
High precision measurement: Provides high-precision measurement and protection functions to ensure the safe and efficient operation of the motor.
User Interface: Equipped with an intuitive graphical user interface (GUI) for easy user configuration, operation, and monitoring.
Communication capability: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., making it easy to integrate with other devices and systems.
technical specifications
Model: 269PLUS-DO-311
Protection function:
Overload protection: detects and responds to situations where the motor load exceeds the set value.
Locking protection: prevents the motor from running in a locked state, reducing the risk of damage.
Thermal protection: Monitor the temperature of the motor to prevent overheating.
Undervoltage protection: prevents the motor from operating under undervoltage conditions and avoids damage.
Overvoltage protection: prevents the motor from operating under overvoltage conditions, ensuring system stability.
Data collection: supports real-time collection and analysis of parameters such as current, voltage, and power factor.
Display and Interface: Equipped with a high-resolution display screen and user-friendly interface.
Communication interface: Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, etc.
Environmental temperature: typically suitable for a working temperature range of 0 ° C to 50 ° C.
Installation method: Supports panel installation or DIN rail installation.
application area
Motor protection: used to protect motors in the power system and ensure their safe operation.
Industrial automation: Provide motor protection and management functions in industrial automation systems.
Building power management: applicable to motor protection and control inside buildings to prevent equipment damage.
Installation and maintenance
Installation: The device is usually installed through a panel or DIN rail. Please refer to the product manual for specific instructions.
Maintenance: The design is simple and easy to maintain and inspect on a daily basis. It is recommended to regularly check the equipment status and connection wires to ensure normal operation.
advantage
High performance protection: Provides comprehensive motor protection functions to ensure the safe and efficient operation of the motor.
Flexibility: Supports multiple protection functions and configuration options to adapt to different motor application requirements.
Compatibility: Supports multiple communication protocols for easy integration with other devices and systems.
User friendly: Equipped with an intuitive interface and features, it simplifies the operation and configuration process.
summary
The GE Multilin 269PLUS-DO-311 motor management relay is a high-performance, comprehensive device designed specifically for motor protection and management. Its comprehensive protection function, high-precision measurement, and powerful communication capability make it an ideal choice for power systems and industrial automation applications.
2.产 品 展 示
