Insulation Amplifier PXUB 201
The insulation amplifier is connected to the tension electronics voltage output.
S1 is normally set for voltage 1:1 ratio.
The output is selected to generate a voltage or current output by means of switch S1 and S2.
Slower response is selected by means of switch S2, position 3.
The switches are located inside the unit.You must open the insulation amplifier to be able to set the switches S1 and S2.
1. Demount the insulation amplifier from the DIN rail.
Use a screw driver to unload the spring at the bottom of the insulation amplifier.
2. Press down the snap-locks on both sides of the insulation amplifier.
3. Pull the top lid open, until you see both the switches S1 and S2.
4. Set the switches S1 and S2.
5. Slide back the top lid to locked position.
6. Remount the insulation amplifier on the DIN railAbout this Chapter
Your measurement system does not need any attention during normal operation. Measurement
runs continuously as long as the system is switched on. However, you need to know how to start
and shut down the system, see Section 4.4 Start-up and shut-down.
4.2 Safety Instructions
Read and follow the safety instructions given in Chapter 1 Introduction, before starting any
operation work. However, local statutory regulations, if stricter, are to take precedence.
4.3 Operating Devices
The LED-indicators and operator keys are described in Figure 4-1.
