3BHB000272R0001驱动控制器,3BHB000272R0001产品颜色
为安装的特定插槽设置系统的I/O配置扫描仪。有关更多信息，请参阅第5.1节，配置扫描仪。
保存程序。
向CLX通电。
将CLX PLC置于程序模式，并将程序传输至CLX PLC。查看您的有关详细信息，请参阅编程软件手册。
3.5.2运行扫描仪以下步骤描述了如何安装和设置SST-PB3-CLX-RLL扫描仪：
1、安装Profibus背板产品安装。笔记确保卸载任何先前的PROFIBUS安装，并在安装新版本的软件之前，请重新启动电脑。
3BHB000272R0001驱动控制器有关更多详细信息，请参阅第5.1.1节，通过RSLogix 5000进行配置
信息如果您使用的是PlantScape，请参阅第5.1.2节，配置通过PlantScape Control Builder。
2、运行安装程序。提供的Windows 2000/XP/Server 2003中的exe文件安装CD。此安装脚本可以选择为安装一组工具与SST PROFIBUS背板模块一起使用。SST-PB3-CLX-RLL扫描仪是背板模块，应使用此选项安装配置工具和相关软件。
选择：开始菜单>SST PROFIBUS配置。
4、选择文件>新建。在PROFIBUS设备库（最左侧窗格）中，选择并拖动SST-PB3-CLX
在网络视图（最右侧窗格）中添加master。如果使用，请选择AOP选项
附加配置文件。
If you are using PlantScape, refer to Section 5.1.2, Configuring Through PlantScape
Control Builder.
4.
Set up your system's I/O configuration for the particular slot in which you installed the
scanner. Refer to Section 5.1, Configuring the Scanner, for more information.
5.
Save your program.
6.
Apply power to the CLX.
7.
Put the CLX PLC in Program mode and transfer the program to the CLX PLC. See your
programming software manuals for details.
3.5.2 Getting the Scanner Running
The following steps describe how to install and set up the SST-PB3-CLX-RLL scanner:
1.
Install Profibus Backplane Products Installation.
Note
Ensure that you uninstall any previous PROFIBUS installation and
reboot your PC before installing a new version of the software.
Refer to Section 5.1.1, Configuring Through RSLogix 5000, for more detailed
information. If you are using PlantScape, refer to refer to Section 5.1.2, Configuring
Through PlantScape Control Builder.
2.
Run the setup.exe file from the supplied Windows 2000/XP/Server 2003
installation CD. This installation script has an option to install a set of tools for
use with SST PROFIBUS backplane modules. The SST-PB3-CLX-RLL scanner
is a backplane module and this option should be used to install the Configuration
Tool and associated software.
3.
Open the SST PROFIBUS Configuration Tool window by selecting: Start Menu >
SST PROFIBUS Configuration.
4.
Select File > New.
5.
In the PROFIBUS Device library (left-most pane), select and drag the SST-PB3-CLX
master into the Network view (right-most pane) to add it. Select AOP option if using
Add-on-Profile.
