该方法将与每个LED相关的百分比相加，以确定参数的值。
1、查看LED显示屏以确定哪些LED点亮。
2、使用表8，对于每个点亮的LED，取相应的百分比（参数%乘数）并加上他们在一起。
如何使用二进制值计算峰值频率：
该方法对与每个LED相关的二进制值求和，然后将该和乘以2.5Hz，以计算后期峰值频率。
XVC517AE10模块1、查看LED显示屏以确定哪些LED点亮。
2、使用表8，为每个点亮的LED取相应的二进制值（峰值频率二进制值）并将它们相加。
3、将该总和乘以2.5Hz，得到峰值频率。确定单一来源：
单源检测的测定很简单。如果没有LED点亮，则未检测到单个光源。如果LED 1点亮，检测到一个光源。两种LED配置如表8所示。
步骤5-重置跳闸寄存器并退出跳闸诊断模式
XVC517AE10模块要重置跳闸寄存器并退出此模式，请按住背景火焰选择按钮至少2秒。
要退出此模式而不重置跳闸寄存器，请同时按下目标火焰选择和后退地面火焰选择按钮。
注：一旦填充，必须重置跳闸寄存器，以存储后续跳闸。它不会自动重置或翻滚。
The method sums the percentage associated with each LED to determine parameter's value.
1. View the LED display to determine which LEDs are lit.
2. Using Table 8, for each lit LED take the corresponding percentage (Parameter % Multiplier) and add
them together.
How to Calculate Peak Frequency using the Binary Value:
The method sums binary values associated with each LED and then multiplies this sum by 2.5Hz to calcu
late peak frequency.
1. View the LED display to determine which LEDs are lit.
2. Using Table 8, for each lit LED take the corresponding binary value (Peak Frequency Binary Value)
and add them together.
3. Multiply this sum times 2.5Hz for the Peak Frequency.
Determining Single Source:
Single Source Detected determination is simple. If no LED is lit, a single source has not been detected. If
LED 1 is lit, a single source has been detected. The two LED configurations are shown in Table 8.
Step 5 - Resetting the Trip Register and Exiting the Trip Diagnosis Mode
To reset the Trip Register and exit this mode, hold the Background Flame Select button for at least 2 sec
onds.
To exit this mode without resetting the Trip Register press both the Target Flame Select and Back
ground Flame Select buttons.
NOTE: Once filled, the Trip Register MUST be reset in order to store subsequent trips. It will NOT auto
matically reset or roll-over.
