531X304IBDASG1数字量扩展模块

1.产 品 资 料 介 绍：

中文资料：

531X304IBDASG1数字量扩展模块的产品特点可以归纳如下：

1. 电气参数：
• 输入电压：支持24VDC或125VDC的输入电压范围，确保模块的灵活性和兼容性。
• 输出电压：稳定输出24VDC的电压，为连接的设备提供稳定的电源供应。
• 最大输出电流：最大输出电流可达10A，满足高功率设备的驱动需求。
2. 物理特性：
• 工作温度范围：可在-40°C至70°C的宽温度范围内正常工作，适应各种工业环境。
• 产品尺寸：120mm x 60mm x 80mm的尺寸设计，使得模块易于安装和集成到各种系统中。
• 产品重量：模块重量为0.5kg，轻便且易于搬运。
3. 性能特点：
• 采样周期：采样周期为100ms，确保快速响应和实时数据处理。
• 冗余设计：采用双电源和处理器设计，提供高可靠性和容错能力。
• 最大I/O点：支持多达384个I/O点，满足大规模系统的扩展需求。
4. 通信协议：
• 支持Modbus、以太网、OPC等通信协议，实现与其他设备的顺畅通信和数据交换。
5. 功能特性：
• 作为数字量扩展模块，支持模拟量输入、开关量输入、脉冲量输入、模拟量输出、开关量输出和流量通道等多种功能。
• 具备断线处理功能，当线路出现故障时，可以自动切换到备用线路，确保系统的稳定运行。
• 通常还具备运算函数功能，如数学运算和逻辑运算，扩展了模块的应用范围。
6. 应用场景：
• 广泛应用于工业自动化、控制系统、仪器仪表、传感器和监测应用中，满足各种工业环境下的需求。

综上所述，531X304IBDASG1数字量扩展模块以其电气参数、物理特性、性能特点、通信协议、功能特性和广泛的应用场景，成为工业自动化领域中的重要组成部分，为各种控制系统提供可靠的数据扩展和通信功能。

1. 英文资料

The product features of the 531X304IBDASG1 digital expansion module can be summarized as follows:

Electrical parameters:

Input voltage: Supports an input voltage range of 24VDC or 125VDC, ensuring the flexibility and compatibility of the module.

Output voltage: Stable output of 24VDC voltage, providing a stable power supply for connected devices.

Maximum output current: The maximum output current can reach 10A, meeting the driving requirements of high-power equipment.

Physical properties:

Working temperature range: Can operate normally within a wide temperature range of -40 ° C to 70 ° C, suitable for various industrial environments.

Product dimensions: Designed with dimensions of 120mm x 60mm x 80mm, the module is easy to install and integrate into various systems.

Product weight: The module weighs 0.5kg, which is lightweight and easy to handle.

Performance characteristics:

Sampling period: The sampling period is 100ms, ensuring fast response and real-time data processing.

Redundant design: Adopting dual power supply and processor design, providing high reliability and fault tolerance.

Maximum I/O points: Supports up to 384 I/O points to meet the scalability requirements of large-scale systems.

Communication protocol:

Support communication protocols such as Modbus, Ethernet, OPC, etc., to achieve smooth communication and data exchange with other devices.

Functional features:

As a digital expansion module, it supports various functions such as analog input, switch input, pulse input, analog output, switch output, and flow channel.

Equipped with disconnection handling function, it can automatically switch to the backup line in case of line failure, ensuring the stable operation of the system.

Usually, it also has the function of arithmetic operations, such as mathematical and logical operations, which expands the application scope of the module.

Application scenario:

Widely used in industrial automation, control systems, instruments, sensors, and monitoring applications to meet the needs of various industrial environments.

In summary, the 531X304IBDASG1 digital expansion module has become an important component in the field of industrial automation due to its electrical parameters, physical characteristics, performance characteristics, communication protocols, functional characteristics, and wide application scenarios, providing reliable data expansion and communication functions for various control systems.

2.产      品      展      示

3.产      品      展      示

HONEYWELL 05704-A-0146 DIGITAL

PROSOFT MVI46-MCM COMMUNICATIO

GESADA-1 输入输出模块

KOLLMORGEN CP310250 伺服驱动器

本篇文章出自瑞昌明盛自动化设备有限公司官网，转载请附上此链接:HTTP://WWW.JIANGXIDCS.COM

品牌：ABB

型号：531X304IBDASG1数字量扩展模块

质保：一年

成色：全新/二手

优势产品：ABB、GE、FOXBORO、TRICONEX、BENTLY、A-B、MOTOROLA、HONEYWELL 、SCHNEIDER

                    WOODWARD、EMERSON、RELIANCE、DEIF、NI、XYVOM等

特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

应用行业：广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、烟草、塑胶机械、电力、水利、水处理/环保、市政工程、锅炉供暖、能源、输配电等

快递方式：国内顺丰、德邦、京东快递包邮，按照实际报价货期发货
