531X303MCPBBG1通讯模块
1.产 品 资 料 介 绍：
中文资料：
531X303MCPBBG1通讯模块的产品特点可以归纳如下：
- 功能丰富：
- 支持自动波形测量，包括周期、频率、宽度、上升时间、下降时间、占空比、过冲、高、低、峰-峰、振幅等多种参数。
- 可显示四种任意组合的波形测量值，提供多样化的波形分析手段。
- 配备波形处理功能，如偏移校正和计算算子（加、减、乘、除），满足复杂信号处理需求。
- 操作灵活：
- 阈值可按百分比或电压设置，方便用户根据实际需求进行调整。
- 提供选通功能，可用屏幕或垂直光标选通测量值，操作便捷。
- 支持自动设置功能，在垂直、水平和触发系统上可用单按钮自动设定，简化配置流程。
- 显示特性：
- 波形样式多样，包括点、向量和可变余辉，适应不同观测需求。
- 刻度板选项丰富，支持全标、网格、交叉线等多种模式，方便用户读取波形数据。
- 电气隔离与滤波：
- 所有I/O接口电路均采用光电隔离，保证工业现场的外电路与PLC内部电路之间的电气隔离，提高系统的抗干扰能力。
- 各输入端均采用R-C滤波器，滤波时间常数一般为10~20ms，有效滤除信号中的高频噪声。
- 模块设计：
- 采用屏蔽措施，防止辐射干扰，确保数据传输的稳定性和可靠性。
- 使用性能优良的开关电源，提供稳定的电力供应，保障模块的正常运行。
英文资料
The product features of the 531X303MCPBBG1 communication module can be summarized as follows:
Rich in features:
Support automatic waveform measurement, including multiple parameters such as cycle, frequency, width, rise time, fall time, duty cycle, overshoot, high, low, peak to peak, amplitude, etc.
It can display four arbitrary combinations of waveform measurement values and provide diverse waveform analysis methods.
Equipped with waveform processing functions, such as offset correction and calculation operators (addition, subtraction, multiplication, division), to meet the needs of complex signal processing.
Flexible operation:
The threshold can be set by percentage or voltage, making it convenient for users to adjust according to their actual needs.
Provide gating function, which can be used to select measurement values on the screen or vertical cursor, making operation convenient.
Support automatic setting function, which can be automatically set with a single button on vertical, horizontal, and trigger systems, simplifying the configuration process.
Display characteristics:
The waveform styles are diverse, including points, vectors, and variable afterglow, suitable for different observation needs.
The scale board has a wide range of options, supporting multiple modes such as full scale, grid, and cross line, making it convenient for users to read waveform data.
Electrical isolation and filtering:
All I/O interface circuits adopt photoelectric isolation to ensure electrical isolation between the external circuits on the industrial site and the internal circuits of the PLC, improving the system's anti-interference ability.
R-C filters are used at each input end, with a filtering time constant of generally 10-20ms, effectively filtering out high-frequency noise in the signal.
Module design:
Adopt shielding measures to prevent radiation interference and ensure the stability and reliability of data transmission.
Use high-performance switching power supplies to provide stable power supply and ensure the normal operation of modules.
2.产 品 展 示
