3BSE043664R1底座模块,3BSE043664R1配置教程
光纤遥控器
扩展器模块（RXM）用于扩展机箱up的操作至距离
主机箱抗静电和电磁干扰。TP867 3BSE043664R1
接口模块•HART模拟输入接口
模块充当4-20 mA模拟输入点
现场HART智能设备和HART主机软件在个人计算机
•HART模拟输出接口
模块充当
4-20 mA模拟输出点
现场HART智能设备和
HART主机软件在3BSE043664R1底座模块,
个人计算机
输入/输出模块
•数字输入模块接收
这些标称值的离散信号
电压：115 VAC/VDC，48
VAC/VDC和24 VAC/VDC。全部的
TMR中提供电压
模块。非TMR模块包括
提供24 VDC和48 VDC
只有速度输入和总计
模块也可用。
•监控数字输出模块
产生离散输出信号
这些标称电压
现场诊断覆盖范围
电路和负载装置：115 VAC，
120 VDC、48 VDC和24 VDC。
•数字输出模块产生
这些的离散输出信号
标称电压：115 VAC，120
Fiber-Optic Remote
Extender Modules (RXM)
For operation of Expansion Chassis up
to 7.5 miles (12 kilometers) away from
the Main Chassis, with exceptional
immunity against electro-static and
electro-magnetic interference.
Interface Modules
•
HART Analog Input Interface
Modules act as an interface between
4-20 mA analog input points from
HART smart devices in the field and
HART Host software running on a
PC.
•
HART Analog Output Interface
Modules act as an interface between
4-20 mA analog output points from
HART smart devices in the field and
HART Host software running on a
PC.
I/O Modules
•
Digital Input Modules receive
discrete signals of these nominal
voltages: 115 VAC/VDC, 48
VAC/VDC, and 24 VAC/VDC. All
voltages are available in TMR
modules. Non-TMR modules are
available in 24 VDC and 48 VDC
only. Speed input and totalization
modules are also available.
•
Supervised Digital Output Modules
produce discrete output signals of
these nominal voltages, with
diagnostic coverage of the field
circuit and load device: 115 VAC,
120 VDC, 48 VDC, and 24 VDC.
•
Digital Output Modules produce
discrete output signals of these
nominal voltages: 115 VAC, 120
