3BSE031151R1处理器模块,3BSE031151R1容错控制器
系统组件及其用途
列出标准产品和他们的型号，以及种标准产品的规格
Tricon概述组件底盘
•主底盘室主处理器、内存备份电池、通信模块和输入/输出模块。PM865K01 3BSE031151R1
•扩展机箱，用于其他高达100英尺（30英尺）的输入/输出模块
远离干管底盘。在受限应用中，高达1000英尺（300英尺）的操作仪表）支持。
•用于输入/输出模块的RXM机箱
距离7.5英里（12公里）
从主机箱。
•机械键控每个插槽3BSE031151R1处理器模块
Tricon通过机械键连接到
与特定类型的
单元这可以防止
将模块安装到
插槽不正确。
用于机箱安装和外壳
规格，见第25页。
电源模块
•为中的模块提供逻辑电源
主、扩展或RXM
底盘。提供24 VDC、115
VAC和230 VAC版本。这个
每个电源的额定功率为
140°F（60°C）时为175瓦。
The Triconex product family includes a
comprehensive range of modules. This
section includes: a summary of the
system components and their uses, a
table that lists standard products and
their model numbers, and a summary of
specifications for each standard product
in the Tricon family
See the Tricon Planning and Installa
tion Guide for complete information.
Summary of Tricon
Components
Chassis
•
Main Chassis—houses Main
Processors, memory back-up
batteries, communication modules
and I/O modules.
•
Expansion Chassis—for additional
I/O modules up to 100 feet (30
meters) away from the Main
Chassis. In restricted applications,
operation up to 1,000 feet (300
meters) is supported.
•
RXM Chassis—for I/O modules up
to 7.5 miles (12 kilometers) away
from the Main Chassis.
•
Mechanical Keying—Each slot in
the Tricon is mechanically keyed to
correspond with a specific type of
module. This prevents the
installation of modules into
improper slots.
For chassis mounting and enclosure
specifications, see page 25.
Power Supply Modules
• Provide logic power to modules in
the Main, Expansion or RXM
Chassis. Available in 24 VDC, 115
VAC and 230 VAC versions. The
power rating of each power supply is
175 watts at 140 ° F (60° C).
