3BSE018876R1数据通信模块,3BSE018876R1中文PDF使用手册
模块用作输入/输出模块
Modbus网络和Rockwell之间
自动化背板。从ControlLogix处理器与操作是异步的
在Modbus网络上。中的5000字寄存器空间3BSE018876R1
模块在处理器和Modbus网络。
许多主机SCADA软件包支持Modbus
协议，而设备通常支持
协议包括多个PLC以及许多其他
市场上的第三方设备。（对于部分列表
对于使用Modbus的设备，请访问ProSoft
ProSoft技术网站的测试部分）。
一般规范
•单插槽–1756背板兼容
•本地或远程机架
•模块被识别为输入/输出
模块，并可以访问处理器内存
处理器和模块之间的数据传输
•梯形图逻辑用于在
模块和处理器。PFSK151 3BSE018876R1
•通过用户定义的
梯子包含示例梯形图文件
The MVI56-MCM module acts as an input/output module
between the Modbus network and the Rockwell
Automation backplane. The data transfer from the
ControlLogix processor is asynchronous from the actions
on the Modbus network. A 5000-word register space in
the module exchanges data between the processor and
the Modbus network.
Many host SCADA packages support the Modbus
protocol, while devices commonly supporting the
protocol include several PLCs, as well as many other
third party devices in the marketplace. (For a partial list
of devices that speak Modbus, please visit the ProSoft
Tested section of the ProSoft Technology web site).
General Specifications
• Single Slot – 1756 backplane compatible
• Local or remote rack
• The module is recognized as an Input/Output
module and has access to processor memory for
data transfer between processor and module
• Ladder Logic is used for data transfer between
module and processor.
• Configuration data obtained through user-defined
ladder. Sample ladder file included
