功能规范
MVI56-HART模块支持HART多点
议定书的实施。以下是一些
模块的一般规格：LXN1604-6
•根据HART Bell 202频率建造
移位键控（FSK）标准以叠加数字
4–20mA顶部低电平信号
o四个独立的HART主端口
LXN1604-6中文PDF使用手册
完全由用户配置
o每个端口最多支持15个设备
o点到点（从地址0）或多点
（从地址1到15）支持的模式
•支持99种通用做法
每个端口用于控制和监视设备的命令
带整数、IEEE754浮点和压缩
ASCII字符串数据块
•突发模式可用于更快地更新数据
从单个从机•支持自动轮询功能
自动从每个HART收集数据
在通道上安装仪表，并将数据存储在
模块数据库
•通信端口可以配置为
辅助主机（即手持配置
设备）
支持的协议：HART协议使用Bell 202
标准移频键控（FSK）数字信号
1200波特通信，低电平叠加
4至20mA模拟测量信号。
Functional Specifications
The MVI56-HART module supports the HART Multidrop
implementation of the protocol. Following are some
general specifications for the module:
• Built in accordance to the HART Bell 202 Frequency
Shift Keying (FSK) standard to superimpose digital
signals at a low level on top of the 4 – 20mA
o Four independent HART master ports that are
completely user-configurable
o Supports up to 15 devices per port
o Point-to-point (slave address 0) or Multidrop
(slave address 1 to 15) modes supported
• Supports 99 universal and common practice
commands per port to control and monitor devices
with integer, IEEE754 floating-point and packed
ASCII character string data blocks
• Burst mode can be used for faster update of data
from a single slave• Supports an auto polling feature that will
automatically collect data from each HART
instrument on the channel and store the data in the
module database
• Communication ports can be configured as a
secondary master (that is, handheld configuration
device)
Protocol Supported: HART protocol uses the Bell 202
standard frequency shift-keying (FSK) digital signal to
communicate at 1200 baud, superimposed at a low level
on the 4 to 20mA analog measurement signal.
