3BSE013177R1模拟量输入输出模块,3BSE013177R1培训教程在基座上安装输入/输出模块1、安装新模块前,拆除模块所在位置的电缆槽敲孔盖住端子板连接电缆。可使用钳子或从膜壳内部压出。要安装输入/输出模块,请定位模块,使模块外壳中的电缆槽连接电缆上方。3、用力向下按压模块。4、如果感觉到阻力,请拆下模块并检查键控(如果使用了键控)。而且确保连接电缆正确位于电缆槽中。将输入/输出模块放置...

  • 功能特性
  • 参数规格
  • 视频
  • 应用案例
  • 下载

3BSE013177R1

    3BSE013177R1模拟量输入输出模块,3BSE013177R1培训教程

    在基座上安装输入/输出模块


    1、安装新模块前,拆除模块所在位置的电缆槽敲孔


    盖住端子板连接电缆。可使用钳子或


    从膜壳内部压出。

    LDGRB-01 3BSE013177R1 (2).jpg


    要安装输入/输出模块,请定位模块,使模块外壳中的电缆槽


    连接电缆上方。3、用力向下按压模块。


    4、如果感觉到阻力,请拆下模块并检查键控(如果使用了键控)。而且


    确保连接电缆正确位于电缆槽中。


    将输入/输出模块放置到基座上后,拧紧其螺栓以将其固定。最大限度


    建议扭矩为9英寸/磅。3BSE013177R1模拟量输入输出模块

    Installing an I/O Module on the Base

    1. Before installing a new module, remove the cable slot knockout(s) wherever the module would

    cover the terminal board connecting cables. The knockout can be removed with pliers, or by

    pressing out from inside the module housing.

    2. To install an I/O module, position the module so that the cable slot in the module housing is

    over the connecting cable.3. Press the module down firmly.

    4. If you feel resistance, remove the module and check the keying (if keying has been used). Also

    be sure the connecting cable is in the cable slot properly.

    5. After placing an I/O module onto the base, tighten its bolts to secure it. Maximum

    recommended torque is 9 in/lbs.


    品牌:ABB

    型号:3BSE013177R1

    产地:瑞士

    质保:365天

    成色:全新/二手

    发货方式:快递发货
