MB802V2 SD系统模块卡件
所示转子惯性值适用于非制动编码器电机。制动器和分解器版本的电机的惯量更高。增量编码器和解析器版本的尺寸有限。出版物MP-PP001O-EN-P–2012年3月版权所有©2012 Rockwell Automation，Inc.保留所有权利。在美国印刷，取代出版物MP-P001N-EN-P–2008年12月连接器和电缆MP系列低惯量电机的新型SpeedTEC DIN连接器版本，允许连接器灵活定向，并可将单个电缆系列用于所有MP系列电机。SpeedTEC DIN连接器旨在提供快速的四分之一圈连接。这提供了一个简单而安全的伺服连接。连接器符合广泛的规范和标准要求：UL认证的NFPA 79柔性DESINA电缆jket着色托盘电缆额定值RoHS和REH 600V绝缘额定值电机电缆罗克韦尔自动化为您的MP系列电机提供全面的电源、馈电和制动电缆选择。配件包括标准和连续流动电缆，长度从1米到90米不等。连续流动的电力和制动电缆符合RoHS和NFPA-79托盘等级，由UL认证的散装电缆组成。Jket颜色符合DESINA规范。电机附件轴封套件适用于MP系列低惯量电机的所有框架尺寸。如果安装正确，密封件在轴上的防护等级为IP66。注意，轴封是需要定期补充的易损件。请参阅《运动控制选择指南》，为您的特定电机选择轴封套件。大多数MP系列电机可使用电机端连接器套件。客户选择自己制造电缆时使用这些电缆。该套件采用金属套管，对电缆jket进行压缩式密封，并根据套件的不同，采用焊接式或压接式连接器插座。罗克韦尔自动化为压接式插座提供压接工具。有关更多信息，请参阅我们的网站：.ab./motion或Kinetix选择指南GMC-SG001x。Allen-Bradley和Kinetix是罗克韦尔自动化的注册商标。SERCOS interfe是德国斯图加特利益集团SERCOS interfe e.V的商标。
Rotor inertia values shown are for non-brake encoder motors. Inertias are higher for brake and resolver versions of the motors. The incremental encoder and resolver versions are available in limited sizes. Publication MP-PP001O-EN-P – March 2012 Copyright © 2012 Rockwell Automation, Inc. All Rights Reserved. Printed in USA. Supersedes publication MP-PP001N-EN-P – December 2008 Connectors and Cables New SpeedTEC DIN connector versions of MP-Series Low-Inertia Motors allow fl exible orientation of connectors and use of a single cable family with all MP-Series motors. The SpeedTEC DIN connectors are designed to provide a quick, one-quarter turn connection. This provides an easy, yet secure servo connection. The connectors meet a wide range of codes and standard requirements: UL-Listed NFPA 79 pliant DESINA cable jket coloring Tray cable rating RoHS and REH 600V insulation rating Motor Cables Rockwell Automation off ers a prehensive selection of power, feedbk, and brake cables for your MP-Series motors. Off erings include standard and continuously fl exing cables, in lengths ranging from 1 meter to 90 meters. The continuously fl exing power and brake cables ply with RoHS and NFPA-79 tray ratings, and are posed of UL-listed bulk cable. Jket coloring is pliant with DESINA specifi cations. Motor cessories Shaft seal kits are available for all frame sizes of the MP-Series Low Inertia motors. When installed correctly, the seals yield an IP66 rating at the shaft. Note that shaft seals are wearing parts that will need to be repled periodically. Refer to the Motion Control Selection Guide to select the shaft seal kit for your specifi c motor. Motor-end connector kits are available for most MP-Series motors. They are used by customers who choose to build their own cables. The kits utilize metallic bkshells, pression-style sealing to the cable jket, and are solder-style or crimp-style connector sockets depending on the kit. Crimping tools are off e by Rockwell Automation for crimp-style sockets. For more information refer to our website: .ab./motion, or the Kinetix selection guide, GMC-SG001x. Allen-Bradley and Kinetix are registe trademarks of Rockwell Automation. SERCOS interfe is a trademark of Interests Group SERCOS interfe e.V of Stuttgart, Germany.
