MOOG D138-002-002加密狗,使用教程D138-002-002
终端组件和电缆
现场输入信号通过以下方式连接到FBM子系统DIN导轨安装终端组件电无源（见图1）。助教FBM201/b/c/d模块有以下几种
形式：
使用聚酰胺（PA）的压缩螺钉型
使用聚氯乙烯的压缩螺钉型（PVC）材料
使用聚酰胺（PA）材料的环耳型
使用聚氯乙烯（PVC）的环耳型
MOOG D138-002-002加密狗第8页的“终端组件”，以获取与FBM201/b/c/d模块一起使用的TA。
可拆卸终端电缆连接DIN导轨通过上的现场连接器将TA安装到FBM安装FBM的底板。结束
电缆有以下几种材料：
聚氨酯
Hypalon XLP。终端电缆有多种类型长度可达30米（98英尺），允许
终端组件安装在外壳或相邻外壳中。见表2用于TAs的终端电缆列表
FBM201/b/c/d模块。
TERMINATION ASSEMBLIES AND CABLES
Field input signals connect to the FBM subsystem via
DIN rail mounted Termination Assemblies, which are
electrically passive (see Figure 1). TAs for the
FBM201/b/c/d modules are available in the following
forms:
Compression screw type using Polyamide (PA)
material
Compression screw type using Polyvinyl Chloride
(PVC) material
Ring lug type using Polyamide (PA) material
Ring lug type using Polyvinyl Chloride (PVC)
material
See “FUNCTIONAL SPECIFICATIONS –
TERMINATION ASSEMBLIES” on page 8 for a list of
TAs used with the FBM201/b/c/d modules.
A removable termination cable connects the DIN rail
mounted TA to the FBM via a field connector on the
baseplate in which the FBM is installed. Termination
cables are available in the following materials:
Polyurethane
Hypalon XLP.
Termination cables are available in a variety of
lengths, up to 30 meters (98 feet), allowing the
Termination Assembly to be mounted in either the
enclosure or in an adjacent enclosure. See Table 2
for a list of termination cables used with the TAs for
the FBM201/b/c/d modules.
