NI PXIe-4145 输入模块采集器
1.产 品 资 料 介 绍：
中文资料：
NI PXIe-4145 是一款高性能的输入模块采集器，它属于National Instruments（NI）的PXI Express（PXIe）系列。这款模块具有多种先进的功能和特性，使其在工业自动化、测试与测量等领域有着广泛的应用。
主要特点
- 四通道源测量单元（SMU）：PXIe-4145是一个四通道的源测量单元，这意味着它可以同时处理四个通道的输入信号，大大提高了数据采集的效率。
- 四象限运行模式：每个通道都集成了远程（4线）传感功能，这有助于实现精确的测量。
- 高采样速率：PXIe-4145的高采样速率使得它能够快速捕获器件的瞬态特性，从而实现对被测器件（DUT）的快速IV特性分析。
- 同步功能：通过高速序列引擎，用户可以实现这些SMU之间的同步或与其他仪器（如开关或高速数字测试模块）的同步。
- SourceAdapt技术：这项技术可以调整PXIe-4145对任何负载的响应，以获得最佳响应，从而最大程度地提高稳定性和减小瞬态特性。
- 广泛的应用支持：PXIe-4145适用于各种工业自动化、测试与测量应用，如电子测试、汽车电子、能源管理等。
应用领域
由于其高性能和灵活性，PXIe-4145在多个领域都有广泛的应用，包括但不限于：
- 电子测试：用于电路板的测试、元件参数的测量等。
- 汽车电子：用于汽车控制系统、电池管理系统等的测试与验证。
- 能源管理：用于太阳能逆变器、风力发电系统等的性能测试。
总结
总的来说，NI PXIe-4145是一款功能强大、性能卓越的输入模块采集器，适用于各种需要高精度、高效率数据采集和测量的应用场景。通过其四通道设计、高采样速率和同步功能，它能够满足复杂系统中对多通道数据采集和精确测量的需求。同时，其广泛的应用支持和灵活的配置选项也使其成为了工业自动化和测试与测量领域的理想选择。
英文资料
NI PXIE-4145 is a high-performance input module collector that belongs to the PXI Express (PXIE) series of National Instruments (NI). This module has multiple advanced functions and features, making it widely used in industrial automation, testing and measurement, and other fields.
main features
Four channel source measurement unit (SMU): PXIE-4145 is a four channel source measurement unit, which means it can process input signals from all four channels simultaneously, greatly improving the efficiency of data acquisition.
Four quadrant operation mode: Each channel is integrated with remote (4-wire) sensing function, which helps achieve accurate measurement.
High sampling rate: The high sampling rate of PXIe-4145 enables it to quickly capture the transient characteristics of the device, thereby achieving fast IV characteristic analysis of the device under test (DUT).
Synchronization function: Through a high-speed sequence engine, users can achieve synchronization between these SMUs or with other instruments (such as switches or high-speed digital testing modules).
Source Adapt technology: This technology can adjust the response of PXIe-4145 to any load to obtain the best response, thereby maximizing stability and reducing transient characteristics.
Wide application support: PXIE-4145 is suitable for various industrial automation, testing and measurement applications, such as electronic testing, automotive electronics, energy management, etc.
application area
Due to its high performance and flexibility, PXIE-4145 has a wide range of applications in multiple fields, including but not limited to:
Electronic testing: used for testing circuit boards, measuring component parameters, etc.
Automotive electronics: used for testing and validation of automotive control systems, battery management systems, etc.
Energy management: used for performance testing of solar inverters, wind power generation systems, etc.
summary
Overall, NI PXIE-4145 is a powerful and high-performance input module collector, suitable for various application scenarios that require high-precision and high-efficiency data collection and measurement. Through its four channel design, high sampling rate, and synchronization function, it can meet the needs of multi-channel data acquisition and accurate measurement in complex systems. Meanwhile, its extensive application support and flexible configuration options make it an ideal choice in the fields of industrial automation and testing and measurement.
2.产 品 展 示
3.产 品 展 示
